Accessing The Web Device Manager - Intel 470F - NetStructure Switch User Manual

C H A P T E
NOTE
The default IP address assigned
to the switch is 192.0.2.1. To
access the switch with the
default IP address, your
workstation must be on the
192.0.2.0 subnet.
Alternatively, you can connect to
the switch using Local
Management and set an IP
address that is on your network.
Then you can access the Web
Device Manager using the new
IP address.
26
470T Ch4.p65
R 4 Intel® NetStructure™ 470T and 470F Switches User Guide

Accessing the Web Device Manager

1 In the Location or Address field of your Web browser type the IP
address of the switch. For example, to use the default IP address of the
switch, type 192.0.2.1 in the Location or Address field and then press
Enter.
2 When prompted, type your user name and password. By default, no
user name or password is assigned. If you set a user name and password
using Local Management, enter those here.
3 Click OK. The Web Device Manager screen appears in your Web
browser.
26 3/31/00, 9:15 AM
