C H A P T E R 4 Using the Web Device Manager
Options include:
•
Default Port VID: Sets the PVID that will be assigned to untagged
traffic on a given port. For example, if port 7's default PVID is 100,
all untagged packets on port 7 will belong to VLAN 100. The default
setting for all ports is VID 1.
•
GVRP: Allows automatic VLAN configuration between the switch
and nodes.
•
Ingress filtering: Allows frames belonging to a specific VLAN to be
forwarded if the port belongs to the same VLAN. Disabling this
setting will cause all frames to be forwarded, regardless of the port's
VLAN membership.
After you change the settings, click Submit.
37
