- Page 1 True Scale Fabric Switches 12000 Series Hardware Installation Guide July 2015 Order Number: G91928004US...
- Page 2 OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. A "Mission Critical Application" is any application in which failure of the Intel Product could result, directly or indirectly, in personal injury or death. SHOULD YOU PURCHASE OR USE INTEL'S PRODUCTS FOR ANY SUCH MISSION CRITICAL APPLICATION, YOU SHALL INDEMNIFY AND HOLD INTEL AND ITS...
-
Page 3: Table Of Contents
2.10.3 Spine Module ..................64 2.10.4 SEEB Module ..................65 2.10.5 12200 and 12300 .................. 66 2.10.6 12800 Fans and Power Supplies............... 67 Intel 12000 Series Product Specifications ............... 69 True Scale Fabric Switches 12000 Series Hardware July 2015 Installation Guide... - Page 4 Management Card Installation or Replacement........... 91 Intel 12300...................... 95 E.2.1 Chassis Replacement................95 E.2.2 Fan/Power Supply Replacement ............... 96 Intel 12800 Series .................... 97 E.3.1 Fan Replacement ................... 97 E.3.2 Power Supply Replacement ..............98 E.3.3 Leaf Module Replacement ............... 99 E.3.4...
- Page 5 12000 Series Switches Figures Laser Safety Information................... 10 Copper Cable Bend Radius..................14 Fiber Optic Bend Radius .................... 15 12200 and 12300 Hat Rails ..................17 Installing the Rack Rails .................... 18 12200 and 12300 Four Post Standard Rack Mounting ............ 18 12200 Hat Rails .......................
- Page 6 12000 Series Switches 8X Ports Enabled ..................... 59 8X Port Statistics ..................... 60 Management Module LEDs ..................61 MRL Active LED ....................... 63 Leaf Module LEDs ....................63 Spine Module LEDs (Double Spine Shown) ..............64 SEEB Module LEDs....................65 12200 and 12300LEDs .....................
- Page 7 12000 Series Switches Date Revision Description May 2013 001US Initial release January 2014 002US Updated document File Info meta data August 2014 003US Update Support link in Section 1.7, “Technical Support” on page 11 July 2015 004US Document revision incremented for release 7.4 §...
- Page 8 12000 Series Switches True Scale Fabric Switches 12000 Series Hardware Installation Guide July 2015 Order Number: G91928004US...
-
Page 9: Introduction
This manual describes the hardware installation and initial configuration tasks for the ® Intel True Scale Fabric Switches 12000 Series that includes: • The Intel 12200 36-port fixed-configuration switch • The Intel 12300 36-port configurable switch • The Intel 12300 18-port configurable switch • The Intel 12800 series: —... -
Page 10: Laser Safety Information
— Press the UP ARROW key. • Text in italics indicates terms, emphasis, variables, or document titles. For example: — For a complete listing of license agreements, refer to the Intel Software End User License Agreement. — What are shortcut keys? —... -
Page 11: Electrostatic Discharge Sensitivity (Esds) Precautions
The assemblies used in the switch chassis are ESD sensitive. Observe ESD handling procedures when handling any assembly used in the switch chassis. License Agreements Refer to the Intel Software End User License Agreement for a complete listing of all license agreements affecting this product. Technical Support Intel True Scale Technical Support for products under warranty is available during local standard working hours excluding Intel Observed Holidays. - Page 12 12000 Series Switches True Scale Fabric Switches 12000 Series Hardware Installation Guide July 2015 Order Number: G91928004US...
-
Page 13: Installation
2.1.1 Cable Requirements Note: For detailed information on all supported cables, please refer to the InfiniBand Cable Matrix. which can be found at www.intel.com/infiniband. 2.1.1.1 Cable Distances When planning the location of the switches, consider the distance limitations for signaling, EMI, and connector compatibility. It is recommended that the user does not exceed specified transmission rate and distance limits. -
Page 14: Copper Cable Bend Radius
12000 Series Switches • Keep all ports and connectors free of dust. • Untwisted Pair (UTP) cables can build up Electrostatic Discharge (ESD) charges when being placed into a new installation. Before installing category 5 UTP cables, discharge ESD from the cable by plugging it into a port on a system that is not powered on. -
Page 15: Uninterruptible Power Supply
12000 Series Switches Table 2. IB Fiber Optic Cable Guidelines InfiniBand Fiber Optic Cable Bend Radii Cable Type Bend Radius 25 millimeters Fiber Optic Standard Cable NOTE: A 50mm diameter is the smallest circle limit Figure 3. Fiber Optic Bend Radius 2.1.2 Uninterruptible Power Supply Consider the following when selecting UPS equipment:... -
Page 16: Tools And Equipment Required
12000 Series Switches 2. Unpack the equipment and inspect for any shipping damage. Any shipping damage should be reported to the shipping company. 3. Verify that the equipment shipped matches the packing list. 4. Mark the rack and install the mounting rails. 5. -
Page 17: Four Post Standard-Depth Rack Installation
12000 Series Switches 2.3.1 Four Post Standard-Depth Rack Installation In a standard-depth rack, the distance between the front and back mounting posts is ~28" (700mm). Mounting rails for the 12200 and 12300 are adjustable to accommodate racks with 26"– 33" between mounting posts. 2.3.1.1 Mounting Hardware Kit Contents: •... -
Page 18: Installing The Rack Rails
12000 Series Switches Figure 5. Installing the Rack Rails 3. Slide the switch into the mounting rails and fasten with M6 screws, one (1) per side. Torque screws to 30in-lb. Figure 6. 12200 and 12300 Four Post Standard Rack Mounting True Scale Fabric Switches 12000 Series Hardware Installation Guide July 2015... -
Page 19: 12200 Four Post Shallow-Depth Rack Installation
12000 Series Switches 2.3.2 12200 Four Post Shallow-Depth Rack Installation In a shallow-depth rack, the distance between the front and back mounting posts is ~16" (400mm). Mounting rails for the 12200 are adjustable to accommodate racks with 14"–20" between mounting posts. 2.3.2.1 Mounting Hardware Kit Contents: •... -
Page 20: 12200 Two Post Rack Installation
12000 Series Switches Figure 8. 12200 Four Post Shallow Rack Mounting 2.3.3 12200 Two Post Rack Installation 2.3.3.1 Mounting Hardware Kit Contents: • One pair of mounting L-brackets, left and right. • #6-32 screws • M6 cage nuts • M6 screws 2.3.3.2 Installation 1. -
Page 21: 12800-040 Installation
12000 Series Switches 12800-040 Installation Note: The following procedures are for installing the switch using variable distances between the front and rear rack posts. 2.4.1 Mounting Hardware Kit Contents Note: The mounting kit contains all of the necessary parts for installing and mounting the switch into a 19"... -
Page 22: Clip Nut Orientation
12000 Series Switches Figure 11. Clip Nut Orientation 2. Install support rails in the rack. Fasten with two (2) M6 screws per EIA rail to pre- installed clip nuts and torque to 30 in-lb. Figure 12. Support Rail Installation True Scale Fabric Switches 12000 Series Hardware Installation Guide July 2015 Order Number: G91928004US... -
Page 23: 12800-120 Installation
12000 Series Switches 3. Orient the chassis such that mounting flanges are in the front of the rack. Install the chassis in the rack. Fasten chassis to the rack with four (4) M6 screws. Torque to 30in-lb. Warning: To avoid injury, use a team of people appropriate to the weight of the product and in conjunction with applicable laws and guidelines. -
Page 24: Installation Tasks
12000 Series Switches • M6 Mounting Screws • M6 Clip Nuts 2.5.2 Installation Tasks 1. If applicable, remove the doors of the rack. 2. Install the clip nuts Install M6 clip nuts in the following locations on EIA rails: Figure 14. Clip Nut Installation Locations For improved stability, orient the clip nuts as shown (i.e., orient the flanges horizontally):... -
Page 25: Support Rail Installation
12000 Series Switches Figure 16. Support Rail Installation 4. Install two (2) rear mounting Hat Brackets on the chassis and fasten with #8–32 screws. There are four (4) screws per bracket. Torque to 30in-lb. True Scale Fabric Switches 12000 Series Hardware July 2015 Installation Guide Order Number: G91928004US... -
Page 26: Hat Bracket Installation
12000 Series Switches Figure 17. Hat Bracket Installation 5. Orient the chassis such that mounting flanges are in the front of the rack. Install the chassis in the rack. Warning: To avoid injury, do not manually lift the chassis when fully loaded. Use a mechanized lift whenever possible. -
Page 27: Mounting Flange Installation
12000 Series Switches Figure 18. Mounting Flange Installation 6. Fasten the chassis to the rack with eight (8) M6 screws. Torque to 30in-lb. True Scale Fabric Switches 12000 Series Hardware July 2015 Installation Guide Order Number: G91928004US... -
Page 28: Chassis Installation
12000 Series Switches Figure 19. Chassis Installation 7. Slide two (2) C-brackets over the Hat brackets that are pre-installed on the chassis. True Scale Fabric Switches 12000 Series Hardware Installation Guide July 2015 Order Number: G91928004US... -
Page 29: C Bracket Installation
12000 Series Switches Figure 20. C Bracket Installation 8. If applicable, install the optional cable management guides. Fasten to the EIA rails with M6 screws. Torque all screws to 30in-lb. True Scale Fabric Switches 12000 Series Hardware July 2015 Installation Guide Order Number: G91928004US... -
Page 30: 12800-180 Installation
12000 Series Switches Figure 21. Cable Management Installation 9. If applicable, replace the door(s) on the rack. 12800-180 Installation 2.6.1 Mounting Hardware Kit Contents: Note: The mounting kit contains all of the necessary parts for installing and mounting the switch into a 19" 4-post server rack, with a distance between front and rear rack posts ranging from 28"... -
Page 31: Selecting A Rack
12000 Series Switches 2.6.2 Selecting a Rack The 12800-180 is a large IB switch capable of supporting up to 432 IB ports operating at QDR speed. It is designed for installations in standard-width, 19"-mount server racks (total width of a rack is typically 24"). However, to effectively route and manage such a large number of cables, it is recommended that a wide server rack is used for installation of 12800-180 switches. -
Page 32: Clip Nut Orientation
12000 Series Switches Figure 23. Clip Nut Orientation 3. Install support rails in the rack. Fasten with two (2) M6 screws per EIA rail to pre- installed clip nuts and torque to 30 in-lb. Figure 24. Support Rail Installation 4. Install four (4) rear mounting brackets to the chassis and fasten with #8–32 screws. -
Page 33: Flat Bracket Installation
12000 Series Switches Figure 25. Flat Bracket Installation 5. Orient the chassis such that mounting flanges are in the front of the rack. Install the chassis in the rack. Warning: To avoid injury, when fully loaded do not lift manually. Use a mechanized lift only. If a manual lift is necessary, first unload all field replaceable units (FRUs) to minimize weight. -
Page 34: Mounting Flange Installation
12000 Series Switches Figure 26. Mounting Flange Installation 7. Slide four (4) C-brackets over the HAT brackets that are pre-installed on the chassis. True Scale Fabric Switches 12000 Series Hardware Installation Guide July 2015 Order Number: G91928004US... -
Page 35: U Bracket Installation
12000 Series Switches Figure 27. U Bracket Installation 8. If applicable, install the optional cable management guides. Fasten to the EIA rails with M6 screws. Torque all screws to 30in-lb. True Scale Fabric Switches 12000 Series Hardware July 2015 Installation Guide Order Number: G91928004US... -
Page 36: 12800-360 Installation
12000 Series Switches Figure 28. Cable Management Guide Installation 9. If applicable, replace the door(s) on the rack. 12800-360 Installation 2.7.1 Mounting Hardware Kit Contents: Note: The following procedures are for installing the switch using variable distances between the front and rear rack posts. •... -
Page 37: Front And Rear Cabling
12000 Series Switches To effectively route and manage cables, it is recommended that a wide server rack is used for installation of the 12800-360 switch. These instructions are for installation in a typical wide server rack 797mm wide x 1021mm deep, or similar, with adjustable vertical EIA rails. -
Page 38: Installation Tasks
12000 Series Switches recirculation control panels should be installed in a rack to minimize airflow recirculation between the hot and cold isles. Recirculation control panels for wide racks and installation instructions are available from rack suppliers. Figure 30. Locating Mounting Posts 2.7.3 Installation Tasks Note:... -
Page 39: Clip Nut Orientation
12000 Series Switches Figure 31. Clip Nut Installation For improved stability, orient the clip nuts as shown (i.e., orient the flanges horizontally): Figure 32. Clip Nut Orientation 2. Attach four (4) mounting brackets to the support shelf as shown in Figure 33. -
Page 40: Support Shelf Assembly
12000 Series Switches Figure 33. Support Shelf Assembly 4. Install the support shelf into the rack. Fasten the M6 screws to pre-installed clip nuts and torque to 30 in-lb. There are three (3) screws per mounting bracket. True Scale Fabric Switches 12000 Series Hardware Installation Guide July 2015 Order Number: G91928004US... -
Page 41: Attaching The Support Shelf To The Rack
12000 Series Switches Figure 34. Attaching the Support Shelf to the Rack 5. Orient and position the chassis for installation in the rack. Warning: To avoid injury, when fully loaded do not lift the 12800-260 manually. Use a mechanized lift only. If a manual lift is necessary, first unload all field replaceable units (FRUs) to minimize weight. -
Page 42: Loading From The Pallet
12000 Series Switches Figure 35. Loading from the Pallet 7. Position the chassis on front on the rack. Use pallet jack to move the chassis. Orient the chassis on a pallet in front of the rack as shown. Chassis rear should be facing front of the rack. -
Page 43: Positioning The Switch
12000 Series Switches Figure 36. Positioning the Switch 8. Installing the chassis in the rack: Align the chassis with the rack. Raise the chassis using a pallet jack such that the bottom of the chassis is at or slightly higher than the top surface of the support shelf pre-installed in the rack. -
Page 44: Fasten The Chassis To The Front Of The Rack
12000 Series Switches 9. Fasten the front of the chassis to the rack by installing the front support bracket and fasten to the base of the chassis with five (5) M6 screws. Fasten to the support shelf with seven (7) #10-32 screws. Torque to 30 in-lb. Figure 38. -
Page 45: Fasten The Chassis To The Back Of The Rack
12000 Series Switches Figure 39. Fasten the Chassis to the Back of the Rack 12. Attach the cable management guides. If applicable, attach the cable management guides to the front and rear EIA mounting rails, and fasten with M6 screws to the pre-installed clip nuts. The guides should be installed such that the wire frame supports line up with the chassis leaf True Scale Fabric Switches 12000 Series Hardware July 2015... -
Page 46: Connect Equipment To The Ports And Power On The System
12000 Series Switches module slots. There are four (4) guides in the front of a rack and four (4) in the rear of a rack. Figure 40. Attaching Cable Management Guides 13. If applicable, replace the door(s) on the rack. Connect Equipment to the Ports and Power On the System Note: Before connecting equipment, it is important to understand the locations of the serial... -
Page 47: And 12300 Serial And Ethernet Ports
12000 Series Switches Figure 41. 12200 and 12300 Serial and Ethernet Ports Figure 42. 12800 Series Serial and Ethernet Ports (SEEB Module) True Scale Fabric Switches 12000 Series Hardware July 2015 Installation Guide Order Number: G91928004US... -
Page 48: Connecting Power
12000 Series Switches 1. Connect a Category 5 or 6 (Cat 5/6) Ethernet cable to the RJ-45 connector(s) on the switch. Connect the other end of the Cat 5/6 to an OOB LAN workstation, another switch or a hub. 2. Connect the switch to IB-enabled host(s)/switch(es) using QDR QSFP IB cables, or to DDR host(s)/switch(es) using a QSFP-CX4 cable. -
Page 49: Bringing Up The System For The First Time
12000 Series Switches Figure 43. DC ON/OFF Switch 5. The switch, power supply, and fan LEDs light up. Bringing Up the System For the First Time 2.9.1 12800-Series Management Module Protective Label Guidelines A management module installed in a 12800 system may have a protective label installed, as shown in Figure 44. -
Page 50: Mrl Protective Label 2
12000 Series Switches 2.9.1.1 Staging Area Testing If a MM requires testing prior to final installation at an end-user site (for example, testing at a staging area), do the following: 1. Disengage the thumb screw and partially rotate the lever as shown in Figure Figure 45. -
Page 51: Start-Up Procedures
12000 Series Switches 2.9.1.2 User Site Installation After final installation of a 12800-series switch is completed at the end user site: 1. Disengage the thumb screw and partially rotate the lever as shown in Figure Figure 48. MRL Protective Label 5 2. -
Page 52: Changing The Switch Ip Address And Default Gateway Through The Cli
12000 Series Switches • Flow control = XON/XOFF 3. Verify the IP address with the CLI command command. The showChassisIpAddr system returns information similar to the following: Chassis IP Address: 192.168.100.9 Net mask: 255.255.240.0 2.9.3 Changing the Switch IP Address and Default Gateway through the CLI The CLI can be accessed two ways: •... -
Page 53: Updating The Management Module Ip Addresses In A Redundant Management Configuration (12800-040, 12800-120, 12800-180 And 12800-360)
12000 Series Switches setDefaultRoute -h <ipaddress> where is the new default gateway IP address in dotted decimal -h <ipaddress> format. 6. The changes are effective immediately. 2.9.4 Updating the Management Module IP Addresses in a Redundant Management Configuration (12800-040, 12800-120, 12800-180 and 12800-360) Each management module must have a unique IP address that is different than the chassis IP address of the switch. -
Page 54: Enabling 8X Ports
12800-series switches. Note: This section focuses on enabling 8x external cable ports. For details on each command, ® refer the Intel True Scale 12000 CLI Reference Guide. 2.9.5.1 Creating an 8x Port: 12200/12300 Note: This section focuses on enabling 8x ports for 12200/12300 switches with an installed management card. -
Page 55: 12200/12300 8X Duos
12000 Series Switches Figure 50. 12200/12300 8x DUOs For example, to combine ports 2 and 20: 1. Log into the switch CLI with the login and password admin adminpass 2. Enable port 2 with a command similar to: ismPortSetWidth Cable02 7 -bounce and press ENTER. -
Page 56: X Ports Enabled
12000 Series Switches Figure 51. 8X Ports Enabled 6. From the Chassis Viewer main menu, click on Port Stats then IB Port Stats to display the IB Port Statistics screen. The 8X port (for DUO of cable ports 10 and 28) is displayed (see Figure 52). -
Page 57: X Port Statistics
12000 Series Switches Figure 52. 8X Port Statistics The first port of the group (port 10) is shown as active and Up; the other port in the DUO (port 28) is displayed as down and Disabled. 2.9.5.2 Creating an 8x Port: Externally-managed 12200 Externally-managed 12200 switches are shipped with all ports having a port width of 1x/4x/8x. -
Page 58: Leaf Module 8X Duos
8x enabled (and are capable of being an 8x connection), but the ® link is up at 4x, certain tools (for example, the Intel FastFabric iba_report -o slowlinks command) may flag this connection as not being linked up at its optimum capability. -
Page 59: X Ports Enabled
12000 Series Switches 2. Enable port 8 with a command similar to: ismPortSetWidth L111P08 7 -bounce. and press ENTER. 3. Enable port 17 using same command as above, changing the port number (that is, L111P17 4. At the switch, unplug and reinsert the cables to the physical ports. After reinserting the first cable, the user has four (4) seconds to reinsert the second cable associated with the 8x connection before the link begins training. -
Page 60: X Port Statistics
12000 Series Switches Figure 55. 8X Port Statistics The first port of the group (port 8) is shown as active and Up, while the other port in the DUO (port 17) is displayed as down and Disabled. True Scale Fabric Switches 12000 Series Hardware Installation Guide July 2015 Order Number: G91928004US... -
Page 61: Component Leds
12000 Series Switches 2.10 Component LEDs 2.10.1 Management Module Figure 56. Management Module LEDs 2.10.1.1 Module Status The status LED indicates one of the following conditions: • Steady Green: the module is operating normally. • Blinking Green: LED test state. •... - Page 62 12000 Series Switches • Any power supply DC OK LED is off • Any spine module Attention LED is on, or it has been determined that a spine is not functioning (even if it is unable to turn on the LED). •...
-
Page 63: Leaf Module
12000 Series Switches Figure 57. MRL Active LED 2.10.2 Leaf Module Figure 58. Leaf Module LEDs True Scale Fabric Switches 12000 Series Hardware July 2015 Installation Guide Order Number: G91928004US... -
Page 64: Spine Module
12000 Series Switches 2.10.2.1 InfiniBand Port LEDs Each module IB port has a Green IB link status LED that provide the following indications: • On: the logical link is up (port is in the Active state). • Off: the physical link is down (port is in the Down state). 2.10.2.2 Module Status The status LED indicates one of the following conditions:... -
Page 65: Seeb Module
12000 Series Switches • Off: module is in the removable state. 2.10.3.2 Module Attention The Attention LED indicates one of the following conditions: • Off: the system functioning normally. • Steady Amber: the system requires some attention, which could indicate one of the following conditions: —... -
Page 66: 12200 And 12300
12000 Series Switches 2.10.4.2 MRL Active The MRL Active LED is Green when the mechanical release latch (MRL) thumbscrew is secured to the serial, Ethernet, Chassis EEPROM Board (SEEB) and a Management Module is installed in the front of the chassis. 2.10.5 12200 and 12300 Figure 61. -
Page 67: 12800 Fans And Power Supplies
12000 Series Switches — The module can no longer function properly. The system will take the appropriate actions to ensure that no damage is done to its components. • Blinking Amber (once every four seconds): LED test state. 2.10.5.4 RJ45 LEDs The RJ45 connectors have two LEDs, Act and 100. -
Page 68: Power Supply Leds
12000 Series Switches Fan LEDs indicate the following status(es): • Green indicates that the fan is functioning properly. • Amber indicates that the following warning condition exists: — A single fan failure when the rotation speed is less than 4000 RPM or greater than 10,950 RPM. -
Page 69: Intel 12000 Series Product Specifications
12000 Series Switches Appendix A Intel 12000 Series Product Specifications Physical Specifications All products within the 12200, 12300 and 12800 Director series are designed to be installed in industry-standard 19-inch four-post server racks. Racks should conform to conventional standards. Use the American National Standards Institute (ANSI)/Electronic Industries Association (EIA) standard ANSI/EIA-310-D-92 and International Electrotechnical Commission (IEC) 297. -
Page 70: Power
12000 Series Switches A.3.2 Power • Power Supply: — Two redundant, hot plug fan/power supplies (12300) — 90/264 VAC operation — 275W max power per supply — Input: 90–264V AC, 47–63Hz, 1 Phase, 3.6A max current at 100VAC — Inrush Current: 13A @ 115VAC, 6.5A @ 230VAC —... -
Page 71: Power Specifications
12000 Series Switches appropriate temperatures of major heat-producing components. Monitoring is performed through a two-wire I2C interface to each fan tray. A.4.1 Power Specifications All products within the 12800 series use a common switching power supply. System power attributes are displayed in Table 5. -
Page 72: Power Distribution Guidelines
Power Distribution Guidelines The following section details power distribution guidelines and recommendations for the ® Intel 12800 series. • The power supplies for the 12800 series have a maximum inlet current of 15amps @ 110volts and 6amps @ 220volts. Please observe power outlet, power strip and extension cable ratings. -
Page 73: Ac Plug Types
12000 Series Switches Figure 64. 12800-Series Power Distribution Table 6. AC Plug Types Voltage Region/Country Plug Type Misc./Notes Rating North America 100–127 NEMA 5– North America 200–240 NEMA L6– North America 200–240 NEMA L15– Three phase AC True Scale Fabric Switches 12000 Series Hardware July 2015 Installation Guide Order Number: G91928004US... - Page 74 12000 Series Switches Table 6. AC Plug Types (Continued) Voltage Region/Country Plug Type Misc./Notes Rating Europe (Schuko) 200–240 CEE 7/7 Used in Austria, Belgium, Finland, France, Germany, Greece, Hungary, Indonesia, The Netherlands, Norway, Poland, Portugal, Russia, Spain, Sweden. International 200–240 IEC 309 3-wire (two-phase and earth).
-
Page 75: Safety And Regulatory Compliance Information
12000 Series Switches Appendix B Safety and Regulatory Compliance Information This section provides regulatory compliance, safety and electromagnetic compatibility ® (EMC) information for the Intel 12000 series products. Safety Information B.1.1 Statement 1: Disconnect Device: This unit may have more than one power cord. To reduce the risk of electrical shock, disconnect all power cords before servicing unit. -
Page 76: Statement 2
12000 Series Switches B.1.1.7 Declaração 1: Desligar dispositivo: Esta unidade pode ter mais de um cabo de alimentação. Para reduzir o risco de choque eléctrico, desligue todos os cabos de alimentação antes de fazer a manutenção da unidade. B.1.1.8 Declaración 1: Desconexión de dispositivo: Esta unidad puede tener más de un cable de alimentación eléctrica. - Page 77 12000 Series Switches ANMERKUNG: Gebruik genoeg mensen voor het gewicht van elk gespecificeerd product en hanteer de toepasselijke richtlijnen. Gebruik waar mogelijk een mechanisch tilapparaat. B.1.2.2 Varoitus 2: Kotelon nostaminen. Noudata nostaessasi turvaohjeita. HUOMAUTUS: Varaa nostamista varten laitteen painoon nähden sopiva ja sovellettavien ohjeiden mukainen määrä...
-
Page 78: Statement 4
12000 Series Switches OBS! Använd ett team personer lämpade för vikten på varje specificerad produkt och i samband med gällande riktlinjer. Använd en mekanisk lyftanordning närhelst det är möjligt. B.1.2.10 Kijelentés 2: A burkolat emelése – Biztonságos eljárásokat alkalmazzon az emelés során. MERK: Az egyes termékek súlyának megfelelo fobol álló... - Page 79 12000 Series Switches B.1.3.3 Déclaration 3 : Danger électrique: Pour réduire le risque d'électrocution, gardez vos mains hors des baies d'alimentation et des zones destinées aux cartes de circuits imprimés. B.1.3.4 Anweisung 3: Gefahr vor elektrischem Schock: Um der Gefahr vor elektrischem Schock vorzubeugen, halten Sie Hände und Finger den Netzteilschächten und der Rückwand fern.
-
Page 80: Statement 6
12000 Series Switches B.1.4 Statement 4: Laser Radiation: certain optical products may emit laser radiation. Removing covers could result in exposure to hazardous laser radiation. Radiation may be emitted from connectors or fiber optic cables. B.1.4.1 Verklaring 4: Laserstraling: bepaalde optische producten kunnen laserstraling verspreiden. Het verwijderen van dekplaten kan resulteren in blootstelling aan schadelijke laserstraling. -
Page 81: B.1.5 Statement 5
12000 Series Switches B.1.4.8 Declaración 4: Radiación de láser: Ciertos productos ópticos pueden emitir radiación de láser. Quitar las cubiertas podría resultar en la exposición peligrosa a radiación de láser. La radiación se puede emitir de conectores o cables de fibra óptica. B.1.4.9 Uttalande 4: Laserstrålning. - Page 82 12000 Series Switches B.1.5.3 Déclaration 5 : Pièces non entretenues par l'utilisateur: Des niveaux d'électricité dangereux peuvent résider à l'intérieur des sources d'alimentation et des modules de carte de circuits imprimés. Ne retirez pas les capots. B.1.5.4 Anweisung 5: Wartung nur durch Fachmann möglich: Gefährlich hohe Stromstärken sind in Netzteilen und in den Modulen der Busleiterplatte vorhanden.
-
Page 83: B.1.6 Statement 6
12000 Series Switches B.1.5.13 B.1.6 Statement 6: Equipment Installation: Only qualified personnel should be allowed to install, remove or replace chassis or modules. B.1.6.1 Verklaring 6: Installatie apparatuur: Voor het installeren, verwijderen of vervangen van chassis of modules mag alleen gekwalificeerd personeel worden gebruikt. B.1.6.2 Varoitus 6: Laitteiston asentaminen. -
Page 84: Statement 7
Statement 7: ® Adding or Replacing Modules: These modules are intended only for installation in Intel 12000 base units. Always install blanks when removing an active module. They prevent exposure to energy hazards inside the unit, contain EMI, and maintain cooling air balance in the chassis. - Page 85 Déclaration 7 : Ajouter ou remplacer des modules: Ces modules sont conçus exclusivement pour une ® installation avec des unités de base Intel 12000 series. Installez toujours des caches de protection lors du retrait d'un module actif. Ils protègent contre les dangers électriques à...
- Page 86 12000 Series Switches B.1.7.10 Kijelentés 7: ® Modulok hozzáadása vagy cseréje – Ezek a modulok kizárólag Intel 12000-es sorozatú bázisegységekbe építhetoek be. Aktív modul cseréjekor mindig szereljen be üres helyeket. Ezek megakadályozzák az egységen belüli energiaveszélyek kialakulását, tartalmaznak EMI-t, és fenntartják a hutolevego egyensúlyát a borításon belül.
-
Page 87: Serial Port Pinouts
Figure 65. Serial Port Pinouts ® Figure 65 represents the RJ-11 connector located on the Intel 12200 and 12300. • The only serial port signals required are: Tx, Rx and Ground. All other serial port signals are NOT used. G91928... -
Page 88: Pinout Cross Reference
12000 Series Switches Table 7 for a list of RJ45 (on Digi) to RJ11 cross references. The cable should connect the three RJ45 signals (on the Digi) to the RJ11 connector. The signals for the T3 card located inside the switch and spine are included for reference only. Table 7. -
Page 89: D 12800 Leaf Module Guidelines
12000 Series Switches Appendix D 12800 Leaf Module Guidelines This section details the general guidelines for populating each 12800-series switch. Each switch has: • Two Management Module (MM) slots with a corresponding management leaf slot. The minimum requirement for each switch is one leaf module per management module. This leaf must be installed in the corresponding management leaf slot. -
Page 90: Single Management Module
12000 Series Switches 12800-360 D.4.1 Single Management Module • MM slot: M228/Leaf module management slot: L127. D.4.2 Dual Management Modules • MM slot: M228/Leaf module management slot: L127. • MM slot: M227/Leaf module management slot: L128. § § True Scale Fabric Switches 12000 Series Hardware Installation Guide July 2015 Order Number: G91928004US... -
Page 91: Fru Replacement
Appendix E FRU Replacement ® This section details replacement information for various Intel 12000 FRUs. For replacement parts, contact Intel or an approved reseller. Note: If it is part of a standard operating procedure, add replacement identification tags to both the rack and the FRU hardware to ensure that the warranty is transferred to the replacement part(s). - Page 92 12000 Series Switches E.1.2.1 Removal Procedures 1. Power down the switch by unplugging AC power. 2. Remove all applicable IB, Ethernet and Serial cables. Set these aside for reinstalling after replacing the management card. 3. Remove the switch from the rack. Keep all rail hardware installed in the rack. 4.
- Page 93 12000 Series Switches Figure 67. 12200 Management Card Insertion 2. Press down on the management card to ensure that is seated properly. True Scale Fabric Switches 12000 Series Hardware July 2015 Installation Guide Order Number: G91928004US...
- Page 94 12000 Series Switches Figure 68. 12200 Management Card Insertion (2) 3. Complete the replacement by re-inserting the screw as displayed in Figure True Scale Fabric Switches 12000 Series Hardware Installation Guide July 2015 Order Number: G91928004US...
-
Page 95: Intel 12300
6. Connect AC power. 7. If applicable, upgrade the switch firmware, and change the switch, gateway and subnet mask addresses to a new network address. 8. Cable all applicable IB ports. Intel 12300 E.2.1 Chassis Replacement FRU part numbers: • Standard 36-port chassis: 12300BS01 •... -
Page 96: Fan/Power Supply Replacement
Fan/Power Supply Replacement FRU part number: • 12300PS01 ® Note: These fan/power supplies are to be used exclusively with the Intel 12300 QDR IB switch and are not intended to be sold separately. E.2.2.1 Removal Procedures 1. Push the finger tab to the right. -
Page 97: Intel 12800 Series
12000 Series Switches E.2.2.2 Replacement Procedures Hold the unit by the handle and slide into the applicable slot until the finger tab clicks into place. Intel 12800 Series E.3.1 Fan Replacement FRU part numbers: • Intake Fan: 12800FITK • Exhaust Fan: 12800FEXH E.3.1.1... -
Page 98: Power Supply Replacement
Power Supply Replacement FRU part number: • 12800PS01 ® Note: These power supplies are to be used exclusively with the Intel 12800 series QDR IB switches and are not intended to be sold separately. E.3.2.1 Removal Procedures 1. Push the release latch to release the arm. -
Page 99: Leaf Module Replacement
12000 Series Switches Figure 73. 12800 Power Removal 2. Carefully pull the supply until it is disengaged from the chassis. E.3.2.2 Replacement Procedures 1. Slide the power supply straight into the open slot until it engages with the backplane connector. 2. - Page 100 12000 Series Switches Figure 74. 1. Pull each release arm down until the leaf module disengages from the backplane connector. True Scale Fabric Switches 12000 Series Hardware Installation Guide July 2015 Order Number: G91928004US...
-
Page 101: Spine Module Replacement
12000 Series Switches Figure 75. 12800 Leaf Removal 2. Carefully pull the module out of the chassis. E.3.3.2 Replacement Procedures 1. Slide the module straight into the open slot until it engages with the backplane connector. 2. Push the arms up until they lock in place. 3. -
Page 102: Management Module Replacement
12000 Series Switches 2. Carefully pull the module out of the chassis. E.3.4.2 Replacement Procedures 1. Slide the module straight into the open slot until it engages with the backplane connector. 2. Push the arms in until they lock in place. 3. - Page 103 12000 Series Switches Note: The standard FRU replacement process for management modules is one at time. This allows the master module to move to a slave state, if necessary. Note: Never replace multiple management modules at the same time. § § True Scale Fabric Switches 12000 Series Hardware July 2015 Installation Guide...
