Downloading HP Vision Diagnostics
If for some reason neither Vision Creator nor HP Vision Diagnostics are available on your workstation,
follow these steps to download HP Vision Diagnostics from the HP Web site and load onto a USB flash
drive or DVD/CD:
Go to http://www.hp.com/go/workstationsupport.
Select your workstation.
Click Download drivers and software.
Select your language and operating system.
Select the Diagnostic link.
Locate HP Vision Diagnostics under "Quick jump to downloads by category..." for either USB
or CD (as desired) and select Download.
Depending on whether you chose USB or DVD/CD:
USB: Run the .exe file that is downloaded, then follow the prompts to save HP Vision
Diagnostics and load it onto a USB flash key.
DVD/CD: Run the .exe file that is downloaded, then follow the installer prompts to extract
and save the .iso file to your hard drive. Use CD-ROM burning software to copy the .iso file
to an optical medium.
When the DVD/CD or USB flash drive has the utility installed, insert the USB flash drive or DVD/
CD into the computer (while it is on).
Shut down the workstation using the operating system.
Turn on the computer. The system should boot into HP Vision Diagnostics.
you may need to change the boot order. You may use the Computer Setup (F10) utility to change
the boot order, or you may press F9 to select the appropriate boot device.
At the boot menu, select either the HP Vision Diagnostics utility to test the various hardware
components in the computer or the HP Memory Test utility to test memory only.
alone application, outside of HP Vision Diagnostics.
If the computer is booted from a DVD/CD, a separate boot DVD/CD will be required to use the
memory diagnostic. Hence, HP recommends that a USB key be used to boot the diagnostic
utilities. It is faster than using a DVD/CD, and it accommodates both the Memory Test and Vision
If running HP Vision Diagnostics, select the appropriate language and click Continue.
In the End User License Agreement page, select Agree if you agree with the terms. The HP Vision
Diagnostics utility launches with the Survey tab displayed
Chapter 6 Diagnostics and troubleshooting
If the system does not boot to the DVD/CD in the optical drive or to the USB flash drive,
The HP Memory Test is a comprehensive memory diagnostic utility that is run as a stand-
