2. Lower the front of the power supply into place behind the chassis tab (see letter
"B").
3. Secure the power supply to the back panel with two screws (see letter "C").
4. Connect all cables, including the power at the rear of the chassis (see letter "D").

Installing and Removing the Rack Handles

Installing the Rack Handles

1. Align the rack handle with the holes on the side of the server system and attach the
rack handle with the two screws.
®
Intel Server System SR1630BC Service Guide

Figure 52. Installing the Power Supply into the Server System

D
B
A
D
B
C
AF002908
57
