Table 7-13
Class: HP_MemoryModuleSlot
Property name
Tag
Description
ElementName
ConnectorLayout
ConnectorDescription
Number

7.3.10HP_MemoryBoardSlot

The class HP_MemoryBoardSlot represents memory board slots on Integrity servers. There is an
instance of this class for each memory board slot in the system (whether the slot is occupied or not).
Table 7-14
Class: HP_MemoryBoardSlot
Property name
Caption
Property implementation
HPQ:HP_MemoryModuleSlot:x-y (for non-cellular
systems)
HPQ:HP_MemoryModuleSlot:c-x-y (for cellular
systems
Where:
•
c is the cabinet number where the memory
module is located.
•
x is the board number where the memory module
is located.
•
y is the socket number where the memory module
is located.
DIMM index#: Socket full location, where
full location includes the cabinet and cell (for
cellular systems) and the extender board # (for systems
that have memory extenders).
DIMM index#: Socket full location, where
full location includes the cabinet and cell (for
cellular systems) and the extender board # (for systems
that have memory extenders).
CIM_PhysicalConnector
1 (Other)
DIMM index#: Socket full location, where
full location includes the cabinet and cell (for
cellular systems) and the extender board # (for systems
that have memory extenders).
CIM_Slot
DIMM index #
HP_MemoryModuleSlot
Property implementation
CIM_ManagedElement
A string describing the memory board physical
location
:
•
System Board
•
Extender x
•
Cabinet x Cell y
System memory 91
