15.3.97HPSA_ DiskDriveTSASSCSIProtocolEndpoint
(Association)
Table 15-98
Property name
AvailableSAP
ManagedElement

15.3.98HPSA_SCSIInitiatorTargetLogicalUnitPath

The following class instance is created only with SAS controllers supporting multipath supported
firmware and configured in dual domain mode.
Table 15-99
Property name
Initiator
Target
LogicalUnit
State

Supported indications

15.4

15.4.1Physical Drive Status Changed to OK

Table 15-100
Property name
IndicationIdentifier
PerceivedSeverity
IndicationTime
Class: HPSA_DiskDriveTSASSCSIProtocolEndpoint (CIM_SAPAvailableForElement)
Class: HPSA_SCSIInitiatorTargetLogicalUnitPath (CIM_ SCSIInitiatorTargetLogicalUnitPath)
HPSA_DeviceIndication: Physical Drive status changed to OK
Property implementation
Points to reference of HPSA_TSASSCSIProtocolEndpoint
Points to reference of HPSA_DiskDrive
Property implementation
Reference to aninstance of
HPSA_ISASSCSIProtocolEndpoint
Reference to an instance of
HPSA_TSASSCSIProtocolEndpoint
Reference to an instance of HPSA_StorageExtent
•
0 (unknown) if the path status cannot be
ascertained
•
2 (active) if the path is active and healthy
•
5 (Path Error) path has an error condition
•
3 (passive) path is healthy but is not active or is
the standby path
Property implementation
CIM_Indication
GUID string generated at the time of indication
2 (Informational)
Time of indication
CIM_AlertIndication
Smart Array 238
