Table 3-4
Class: HP_ProcessorCore
Property name
Description
ElementName
Name
OperationalStatus[0]
OperationalStatus[1]
StatusDescriptions
HealthState
Property implementation
processor brand string ia64 Processor Family x Model
y Stepping z (Cabinet p - Cell c Socket s Core o),
where processor brand string is the processor brand
string, x is the processor family number, y is the
processor model number, z is the processor stepping
number, p is the cabinet number, c is the cell number, s
is the socket number, and o is the core number.
Example:
Intel(R) Itanium(TM) 1600MHz ia64 Processor Family
31 Model 1 Stepping 5 (Cabinet 0 Cell 3 Socket 0
Core 0)
•
Cabinet x Cell y Socket z Core m (for
cellular systems)
•
Socket z Core m (for non-cellular systems)
CIM_ManagedSystemElement
•
Cabinet x Cell y Socket z Core m (for
cellular systems)
•
Socket z Core m (for non-cellular systems)
•
0 (Unknown)
•
2 (OK), when CPU is enabled and operational
•
2 (OK), when deconfigured by user from EFI
•
6 (Error), when deconfigured by firmware
because of failure
•
10 (Stopped), when deconfigured by user from
EFI
StatusDescriptions[0] text per OperationalStatus[0]:
•
Processor-module status unknown.
•
Processor-module status OK
•
Processor-module is degraded, it is
predicted to Fail
•
Processor-module in Slot: a Socket:
b disabled by BIOS (POST Error), where
a is the slot number and b is the socket number
•
Processor-module in Slot: a Socket:
b disabled by User through BIOS
Setup, where a is the slot number and b is the
socket number
•
0 (Unknown), when OperationalStatus[0]=0
(Unknown)
•
5 (OK), when OperationalStatus[0]=2 (OK)
•
20 (Major Failure), when OperationalStatus[0]=6
(Error)
CIM_LogicalElement
CIM_EnabledLogicalElement
CPU 35
