15.3.29 HPSA_DiskDriveLocation

HPSA_DiskDriveLocation represents a location string for the disk drive.
Table 15-30
Property name
Caption
Description
ElementName
Name
PhysicalPosition
ElementLocationTag
ElementLocationTagDesc

15.3.30HPSA_ArrayControllerLocation

HPSA_ArrayControllerLocation represents a location string for the array controller.
Table 15-31
Property name
Class: HPSA_DiskDriveLocation (HP_Location)
Class: HPSA_ArrayControllerLocation (HP_Location)
Property implementation
CIM_ManagedElement
Controller name, Drive Type, and Disk Location
For example, Smart Array E500 Physical Drive – Port:
1E Box 1 Bay: 5
Controller name, Drive Type, and Disk Location
For example, Smart Array E500 Physical Drive – Port:
1E Box 1 Bay: 5
Controller name, Drive Type, and Disk Location
Examples:
Smart Array E500 Physical Drive – Port: 1E Box 1 Bay:
5
Smart Array E500 Physical Drive - Port: 1E,2E Box 1
Bay: 5" (SAS disk with dual port)
CIM_Location
Opaque key
Opaque key
HP_Location
•
Bay Number of Disk Drive— When 'Bay' is
specified in ElementLocationTagDesc.
•
SCSI ID of Disk Drive—When 'SCSI ID' is
specified in ElementLocationTagDesc
•
20 (Bay)—When firmware supports Bay
numbering
•
21 (SCSI ID)
HPSA_DiskDriveLocation
Property implementation
CIM_ManagedElement
Smart Array 216
