Table 15-35
Property name
Name
SystemnCreationClassName
SystemName
CreationClassName
EnabledDefault
RequestedState
ProtocolIFType
OtherTypeDescription
Role
Path

15.3.35HPSA_ISASSCSIProtocolEndpoint

HPSA_ISASSCSIProtocolEndpoint represents each port on the smart array controller. This class is
generated only if the SAS controller has multipath supported firmware.
Table 15-36
Property name
Class: HPSA_TSASSCSIProtocolEndpoint
CIM_EnabledLogicalElement
HPSA_SCSIProtocolEndpoint
HPSA_TSASSCSIProtocolEndpoint
Class: HPSA_ISASSCSIProtocolEndpoint
Property implementation
HPSA_DiskDrive.DeviceID:unique value,
where HPSA_DiskDrive.DeviceID is the DeviceID
property of the instance of HPSA_DiskDrive associated
to this instance via the association
HPSA_DiskDriveTSASSCSIPE, and unique value is
a unique value across all instances of
HPSA_TSASSCSIProtocolEndpoint. For example, a
dual port disk has two instances of
HPSA_TSASSCSIProtocolEndpoint with the name
properties set to:
•
PH77MW3991:0:0
•
PH77MW3991:0:1
CIM_ServiceAccessPoint
HPSA_ArraySystem
The property value of HP_ArraySystem.name
HPSA_TSASSCSIProtocolEndpoint
2 (Enabled)
12 (Not Applicable)
1 (Other)
SCSI
3 (Target)
Redundancy path status
•
0 (Unknown)
•
2 (Active)
•
3 (Passiver)
•
5 (Path Error)
Property implementation
CIM_ManagedElement
Smart Array 221
