Table 5-10
Class: HP_FanModule
Property name
PackageType
RemovalConditions

5.3.10HP_FanSlot

HP_FanSlot represents fan slot on Integrity Servers. There will be an instance of this class for each fan
slot in the system (whether the slot is occupied or not).
Table 5-11
Class: HP_FanModule
Property name
Caption
HealthState
Name
OperationalStatus[0]
StatusDescription[0]
CreationClassName
Tag
Description
ElementName
ConnectorLayout
ConnectorPinout
ConnectorType
Number
Property implementation
7 (Fan)
•
3 (Removable when off)
•
4 (Removable when on or off)
HP_Fan
Property implementation
CIM_ManagedElement
Fan n, where n is the physical slot number.
CIM_ManagedSystemElement
•
5 (OK) – if fan is operating properly
•
20 (Major Failure) – if fan has failed
Fan n, where n is the physical slot number.
•
2 (OK) – if fan is operating properly;
•
6 (Error) – if fan has failed
•
Fan is operating properly – if
OperationalStatus[0] is 2 (OK)
•
Fan has failed – if OperationalStatus is 6
(Error)
CIM_PhysicalElement
HP_FanSlot
Fan n, where n is the physical slot number.
Fan n, where n is the physical slot number.
Fan n, where n is the physical slot number.
CIM_PhysicalConnector
7 (Slot)
Custom Fan Slot
76 (Proprietary) – Custom Fan slot
CIM_Slot
The physical fan slot number.
System fan 70
