Chapter 2
Preparing for Installation
Figure 2-6
Figure 2-7
Figure 2-8
OL-4503-26
CAB-7513ACR=
Plug: IRAM 2073
CAB-7513ACA=
Cordset rating: 15 A, 250 V
Length: 14 ft 0 in. (4.26 m)
Plug: SAA AS 3112
CAB-7513ACE=
Plug: CEE 7/7
Cordset rating: 10 A, 250 V
Length: 14 ft 0 in. (4.26 m)
Connector: IEC 60320 C19
Connector: IEC 60320 C19
Cordset rating: 16 A, 250 V
Length: 14 ft 0 in. (4.26 m)
Connector: IEC 60320 C19
Cisco 7600 Series Router Installation Guide
Power Connection Guidelines
2-27
