Chapter 2 Preparing for Installation
Table 2-15 Power Requirements and Heat Dissipation—Service Modules (continued)
Model Number/
Module Type
WS-SVC-NAM-1
Network Analysis Module 1
WS-SVC-NAM-2
Network Analysis Module 2
WS-SVC-PSD-1
Persistent Storage Device
module
WS-SVC-WEBVPN-K9
WebVPN Services module
WS-SVC-WISM-1-K9
Wireless Services Module
(WiSM)
WS-SVC-WLAN-1-K9
Wireless LAN Services module
WS-X6066-SLB-S-K9
Content Switching module with
SSL
Table 2-16
Table 2-16 Power Requirements and Heat Dissipation—SIPs
Model Number/
Module Type
7600-SIP-200
7600-SIP-400
7600-SIP-600
Table 2-17
Table 2-17 Power Requirements and Heat Dissipation—Ethernet Services
Model Number/
Module Type
7600-ES20-10G3CXL
7600-ES20-10G3C
OL-4503-26
Module Module
Current (A) Power
(Watts)
2.89 121.38
3.47 145.74
4.00 168.0
2.94 123.48
6.07 254.94
3.10 130.20
2.15 90.30
lists the power and the heat numbers for SIP modules.
Module Module
Current (A) Power
@ 42 VDC (Watts)
5.69 239
5.95 250
6.42 270
lists the power and the heat numbers for Ethernet Services modules.
Module Module
Current (A) Power
@ 42 VDC (Watts)
8.11 341
8.11 341
AC DC
AC-Input Heat Diss. DC-Input
Power (BTU/HR) Power
(Watts) (Watts)
151.73 518.14 163.15
182.18 622.13 195.89
210.0 717.15 225.81
154.35 527.11 165.97
318.68 1088.25 342.66
162.75 555.79 175.0
112.88 385.47 121.37
AC DC
AC-Input Heat Diss. DC-Input
Power (BTU/HR) Power
(Watts) (Watts)
299 1021 322
312 1065 338
338 1153 363
AC DC
AC-Input Heat Diss. DC-Input
Power (BTU/HR) Power
(Watts) (Watts)
426 1454 458
426 1454 458
Cisco 7600 Series Router Installation Guide
Site Requirements
Heat Diss.
(BTU/HR)
557.14
668.95
771.13
566.78
1170.19
597.63
414.48
Heat Diss.
(BTU/HR)
1100
1154
1240
Heat Diss.
(BTU/HR)
1563
1563
