Chapter 3
Installing the Cisco 7600 Series Router
Figure 3-14
Left L bracket
Install the eight or ten (four or five per side) 12-24 x 3/4-inch or 10-32 x 3/4-inch screws through the
Step 3
holes in the bracket and into the threaded holes in the equipment rack posts.
Note
Use a tape measure and level to verify that the chassis is installed straight and level.
Step 4
Installing the Stabilizer Kit (Cisco 7609 Router, Cisco 7609-S, and
Cisco 7613 Router Only)
The stabilizer kit is included only in the accessory kits for the Cisco 7609 Router and Cisco 7613 Router.
Note
If you are not installing the Cisco 7609 router, Cisco 7609-S router, or Cisco 7613 Router in a rack, you
must install stabilizer brackets to the bottom of the chassis. The stabilizer brackets reduce the possibility
that the freestanding chassis will tip over.
OL-4503-26
Installing the Stabilizer Kit (Cisco 7609 Router, Cisco 7609-S, and Cisco 7613 Router Only)
nstalling the Cisco 7609-S Router in a Four-Post Rack
Crossbar bracket
For four-post rack-mounting, install the eight or ten (four or five per side) 12-24 x 3/4-inch or
10-32 x 3/4-inch screws through the holes in the bracket and into the threaded holes in the
addtional equipment rack posts. See
Right L bracket
Shelf bracket
Figure
3-14.
Cisco 7600 Series Router Installation Guide
3-13
