Appendix A Technical Specifications
Table A-9 Power Supply Specifications (continued)
Item
Maximum Torque
Lugs Required
6000 W AC-input Power Supply
AC-input type
AC-input voltage rating
AC-input current rating
Power supply output capacity
AC-input frequency
Power supply output
KVA rating
Output holdup time
1. Power factor correction is a standard feature on all Cisco 7600 series AC-input power supplies. PFC reduces the reactive
component in the source AC current allowing higher power factors (typically 99 percent or better) and lower harmonic current
components.

Regulatory Standards Compliance

The Cisco 7600 series routers comply with the regulatory standards listed in the Regulatory Compliance
and Safety Information for the Cisco 7600 Series Routers document.
OL-4503-26
Specification
36 inch-lb.
Industry Standard 2-hole compression lug with holes on
5/8- inch centers
Specification
High-line input with power factor correction (PFC)
included
Single-phase, 100 to 120 VAC, 200 to 240 VAC (±10% for
full range)
16 A each input
2900 W maximum (one input active at 220 VAC, or
•
both inputs active and one input is 110 VAC and the
other is 220 VAC)
• 6000 W maximum (both inputs active at 220 VAC)
50/60 Hz (nominal) (±3% for full range)
2900 W operation (one 220 VAC source or two
•
110 VAC sources)
25 A @ +3.3 V
–
12 A @ +12 V
–
63.6 A @ +42 V
–
6000 W operation (two 220 VAC sources)
•
25 A @ +3.3 V
–
12 A @ +12 V
–
137.4 A @ +42 V
–
7.2 KVA (high-line operation)
20 ms minimum
•
Regulatory Standards Compliance
