Chapter 2 Preparing for Installation
Table 2-10 Power Requirements and Heat Dissipation—10/100/1000 Ethernet Switching Modules (continued)
Model Number/
Module Type
WS-X6148A-GE-45AF
48-port 10/100/1000 Ethernet
module with WS-F6K-GE48-AF
PoE daughter card
WS-X6516-GE-TX
16-port 10/100/1000 Ethernet
module
WS-X6548-GE-TX
48-port 10/100/1000 Ethernet
module
WS-X6548V-GE-TX
10/100/1000 Ethernet module
with WS-F6K-VPWR-GE PoE
daughter card
WS-X6548-GE-45AF
48-port 10/100/1000 Ethernet
module with WS-F6K-GE48-AF
PoE daughter card
WS-X6748-GE-TX
10/100/1000 Ethernet module
Table 2-11
Table 2-11 Power Requirements and Heat Dissipation—Fast Ethernet Switching Modules
Model Number/
Module Type
WS-X6148-FE-SFP
48-port 100BASE-X module
WS-X6224-100FX-MT
24-port 100BASE-FX Ethernet
module, MMF
WS-X6324-100FX-MM
24-port 100BASE-FX Ethernet
module, MMF
OL-4503-26
Module Module
Current (A) Power
(Watts)
2.68 112.56
3.45 144.90
2.98 125.16
3.40 142.80
3.16 132.72
7.00 294.00
lists the power and the heat numbers for the Fast Ethernet switching modules.
Module Module
Current (A) Power
(Watts)
2.3 96.60
1.90 79.8
1.52 63.84
AC DC
AC-Input Heat Diss. DC-Input
Power (BTU/HR) Power
(Watts) (Watts)
140.70 480.49 151.29
181.13 618.54 194.76
156.45 534.28 168.23
178.50 609.58 191.94
165.90 566.55 178.39
367.50 1255.01 395.16
AC DC
AC-Input Heat Diss. DC-Input
Power (BTU/HR) Power
(Watts) (Watts)
120.75 412.36 129.84
99.75 340.65 107.26
79.8 272.52 85.81
Cisco 7600 Series Router Installation Guide
Site Requirements
Heat Diss.
(BTU/HR)
516.66
665.10
574.49
655.46
609.19
1349.48
Heat Diss.
(BTU/HR)
443.40
366.3
293.03
2-13
