Cisco 7603-S Router

Slot 2 can contain a redundant supervisor engine that can act as a backup if the first supervisor engine
fails. If a redundant supervisor engine is not required, slot 2 is available for other supported line cards.
Both supervisor engines in a single chassis must be identical.
Note
The GBIC uplink ports are fully functional on the redundant supervisor engine in standby mode.
Note
The Cisco 7603-S router supports the following supervisor engines:
Supervisor Engine 32
•
Supervisor Engine 720
•
Route Switch Processor 720
•
The Cisco 7603-S router does not support Supervisor Engine 2.
Note
The Cisco 7603-S router also supports:
•
–
–
–
Note OSMs and FlexWAN modules are not supported in the Cisco 7603-S.
Note The Switch Fabric Module is supported on the Cisco 7603-S router.
The power supplies are installed from the rear of the chassis. (See
For a detailed description of supervisor engine and route switch processor operation in a redundant
configuration, refer to the Cisco 7600 Series Router Supervisor Engine and Route Switch Processor
Guide.
Cisco 7600 Series Router Installation Guide
1-4
Up to two additional hot-swappable line cards or Catalyst 6500 series modules
Hot-swappable fan assembly
Redundant DC-input or DC-input power supplies (1500 W)
Chapter 1 Product Overview
Figure 1-4.)
