Appendix A Technical Specifications
Table A-8 Cisco 7613 Router Specifications (continued)
Item
Airflow
Acoustical Noise
1. Designed and tested for normal operation for altitudes up to 10000 ft (3048m); safety approvals apply only to an operating
altitude of 6500 feet (2000 m).
2. RU = rack units

Cisco 7600 Series Router Power Supplies

Table A-9
Table A-9 Power Supply Specifications
Item
950 W AC- and DC-input Power Supplies
AC-input type
AC-input voltage rating
AC-input current rating
AC-input frequency
Power supply output capacity
DC-input voltage rating
DC-input current rating
Power supply output (AC supply)
Power supply output (DC supply)
Output holdup time
1400 W AC-input Power Supplies
AC-input type
AC-input voltage rating
AC-input current rating
AC-input frequency
Power supply output capacity
Power supply output
OL-4503-26
Specification
WS-C6K-13SLT-FAN2 (Optional high-speed fan
tray)—1090 CFM
61.4 to 77 dB. International Organization for
Standardization (ISO) 7779: Bystander position
operating to an ambient temperature of 86°F (30°C).
lists the specifications for the Cisco 7600 series router power supplies.
Specification
Autoranging input with power factor corrector
100 to 240 VAC (±10% for full range)
12-5 A
50/60 Hz (nominal)
950 W maximum (100–240 VAC)
-48 VDC to -60 VDC continuous
25 A
+1.5V @ 15A, +3.3V @ 2.5A, +50V @ 19.15A
+1.5V @ 15A, +3.3V @ 2.5A, +50V @ 19.15A
20 ms minimum (AC-input power supply)
4 ms (DC-input power supply)
Specification
Autoranging input with power factor corrector
100 to 240 VAC (±10% for full range)
16 A @ 100 VAC
•
8 A @ 240 VAC
•
50/60 Hz (nominal) (±3 Hz for full range)
1400 W
15.0 A @ 1.5V
•
2.5A @ 3.3V
•
27.4 A @ 50V
•
