Cisco 7613 Router
The Cisco 7609-S router supports the following:
•
•
•
•
•
•
The Cisco 7609-S router does not support OSMs, Supervisor Engine 2, and FlexWAN (it does support
Note
Enhanced FlexWAN).
For a detailed description of supervisor engine operation in a redundant configuration, refer to the
Cisco 7600 Series Router Supervisor Engine and Route Switch Processor Guide.
Cisco 7613 Router
The Cisco 7613 Router chassis has thirteen slots that are numbered from top to bottom. (See
Figure
The Cisco 7613 router supports the following:
•
Cisco 7600 Series Router Installation Guide
1-14
Both supervisor engines in a single chassis must be completely identical.
Note
A Supervisor Engine 720 in slot 5 and an optional redundant Supervisor Engine 720 in slot 6. Each
supervisor engine provides switching, local and remote management. The Supervisor Enigne 720
has two GBIC uplink ports and one 10/100/1000 Tx port. Only two of the three ports can be active
at any one time.
Note The GBIC uplink ports are fully functional on the redundant supervisor engine in standby
mode.
A Supervisor Engine 32 in slot 5 and an optional redundant Supervisor Engine 32 in slot 6. Each
supervisor engine provides switching, local and remote management.
A Route Switch Processor 720 in slot 5 and an optional redundant Route Switch Processor 720 in
slot 6. Each supervisor engine provides switching, local and remote management.
Both supervisor engines in a single chassis must be completely identical.
Note
Up to eight additional hot-swappable OSMs or Catalyst 6500 series modules
Hot-swappable, redundant fan assemblies
Redundant AC-input and DC-input ) power supplies
1-12.)
A Supervisor Engine 2 in slot 1 and an optional redundant Supervisor Engine 2 in slot 2. Each
supervisor engine provides switching, local and remote management, and multiple GBIC uplink
ports. If a redundant supervisor engine is not required, slot 2 is available for an OSM or other
supported Catalyst 6500 series modules.
The GBIC uplink ports are fully functional on the redundant supervisor engine in standby
Note
mode.
Chapter 1 Product Overview
OL-4503-26
