Chapter 3 Installing the Cisco 7600 Series Router
•
•
•
•
To connect a terminal using a Catalyst 5000 family Supervisor Engine III console cable, perform these
steps:
Step 1 Place the console port mode switch in the out position.
Connect to the port using the Supervisor Engine III cable and the appropriate adapter for the terminal
Step 2
connection.
Step 3 Position the cable in the cable guide (if installed). Make sure there are no sharp bends in the cable.
Step 4 Check the terminal documentation to determine the baud rate. The baud rate of the terminal must match
the default baud rate (9600 baud) of the console port. Set up the terminal as follows:
•
•
•
•
To connect a modem to the console port, perform these steps:
Step 1 Place the console port mode switch in the in position.
Connect to the port using the RJ-45-to-RJ-45 rollover cable and the RJ-45-to-DB-25 DCE adapter
Step 2
(labeled "Modem").
Step 3 Position the cable in the cable guide (if installed). Make sure there are no sharp bends in the cable.

Connecting the Supervisor Engine Uplink Ports

This section describes how to connect to the supervisor engine uplink ports.
Because invisible laser radiation may be emitted from the aperture of the port when no cable is
Warning
connected, avoid exposure to laser radiation and do not stare into open apertures.
In a redundant configuration with two supervisor engines, the uplink ports on the redundant (standby)
Note
supervisor engine are active and can be used for normal traffic, like any other ports in the chassis.
To connect to the supervisor engine uplink ports, perform these steps:
OL-4503-26
9600 baud
8 data bits
No parity
2 stop bits
9600 baud
8 data bits
No parity
2 stop bits
Attaching the Interface Cables
Cisco 7600 Series Router Installation Guide
3-27
