Chapter 5 Removal and Replacement Procedures
Figure 5-3
Figure 5-4
Power
switch
Cisco 7603 router, Cisco 7609 router, Cisco 7609-S, and Cisco 7613 router—Grasp the power supply
Step 5
handle with one hand and slide the power supply part of the way out of the chassis. Place your other hand
underneath the power supply (see
609-S, and Cisco 7613 routers), and slide the power supply completely out of the chassis.
Cisco 7604, Cisco 7606 router, Cisco 7606-S router—Grasp both power supply handles, as shown in
Figure
OL-4503-26
Cisco 7604 Router , Cisco 7606 Router, Cisco 7606-S—Power Supply Captive
Installation Screws
Status LEDs
Captive installation screws
Cisco 7609 Router, Cisco 7609-S Router, and Cisco 7613 Router— Power Supply
Captive Installation Screws
I
0
INPU T
OK
Status LEDs
Captive installation
screw
5-7, and slide the power supply completely out of the chassis.
FAN
OUT PUT
OK
FAIL
Figure 5-5 for Cisco 7603 router, and
Cisco 7600 Series Router Installation Guide
Removing and Replacing the Power Supply
Figure 5-6 for Cisco 7609, Cisco
5-5
