Connector Specifications
The SC-type fiber connector, shown in
external network.
Figure B-5

Gigabit Interface Converters

Because invisible laser radiation may be emitted from the aperture of the port when no cable is
Warning
connected, avoid exposure to laser radiation and do not stare into open apertures. Statement 70
A GBIC is a hot-swappable input/output device that plugs into a Gigabit Ethernet module, linking the
module with the fiber-optic network. GBICs are available in two physical models. There are three optical
models and 32 dense wavelength division multiplexing (DWDM) models. The two physical models are
shown in
Table
Figure B-6
Receiver
Table B-1
GBIC
Short wavelength
(1000BASE-SX)
Long wavelength/long haul
(1000BASE-LX/LH)
Extended distance
(1000BASE-ZX)
Cisco 7600 Series Router Installation Guide
B-4
SC-Type Fiber-Optic Connector
Figure B-6. The three optical models are listed in
B-2.
GBIC Physical Styles
Clip
Transmitter
GBIC Optical Model List
Figure B-5, is used to connect fiber-optic module ports with the
Table
Handle
Receiver
Transmitter
Product Number
WS-G5484
WS-G5486
WS-G5487
Appendix B Connector and Cable Specifications
B-1. The DWDM models are listed in
OL-4503-26
