Preventing Electrostatic Discharge Damage - Cisco 7600-SIP-400 - SPA Interface Processor 400 Installation Manual

Removal and Replacement Procedures
This chapter describes how to perform removal and replacement procedures for Cisco 7600 series router
field-replaceable units (FRUs). It contains the following sections:
•
•
•
•
•
•
•
•
•
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Warning
Caution Use two hands to support the power supply during removal and replacement procedures.
Warning During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not directly
touch the backplane with your hand or any metal tool, or you could shock yourself.
For instructions on installing and replacing modules, refer to the Cisco 7600 Series Internet Router
Module Installation Guide.

Preventing Electrostatic Discharge Damage

Electrostatic discharge (ESD) damage, which can occur when electronic cards or components are
improperly handled, results in complete or intermittent failures. Port adapters and processor modules
consist of printed circuit boards that are fixed in metal carriers. Electromagnetic interference (EMI)
shielding and connectors are integral components of the carrier. Although the metal carrier helps to
protect the board from ESD, use a preventive antistatic strap during handling.
OL-4503-26
Preventing Electrostatic Discharge Damage, page 5-1
Removing and Replacing the Power Supply, page 5-2
Removing and Replacing the PEM, page 5-112
Removing and Replacing the Fan Assembly, page 5-119
Installing the Air Filter Assembly on a Cisco 7606 Router and the Cisco 7606-S Router (Optional),
page 5-126
Replacing the Air Filter on a Cisco 7609 Router and the Cisco 7609-S Router (Optional), page 5-131
Installing the Thermistor Module on a Cisco 7606-S Router, page 5-133
Installing the Thermistor Module on a Cisco 7609-S Router, page 5-134
Upgrading the Cisco 7600 Series Routers to a WS-SUP720-3BXL, page 5-136
