Routing
H3C Low-End Ethernet Switches Configuration Examples
# Create a routing policy named apply_med_50, and specify node 10 with the permit
matching mode for the routing policy. Set the MED value of the route matching ACL
2000 to 50.
[SwitchA] route-policy apply_med_50 permit node 10
[SwitchA-route-policy] if-match acl 2000
[SwitchA-route-policy] apply cost 50
[SwitchA-route-policy] quit
# Create a routing policy named apply_med_100, and specify node 10 with the permit
matching mode for the routing policy. Set the MED value of the route matching ACL
2000 to 100.
[SwitchA] route-policy apply_med_100 permit node 10
[SwitchA-route-policy] if-match acl 2000
[SwitchA-route-policy] apply cost 100
[SwitchA-route-policy] quit
# Apply the routing policy apply_med_50 to routing updates to the peer group ex193
(the peer 193.1.1.2) and apply_med_100 to routing updates to the peer group ex192
(the peer 192.1.1.2).
[SwitchA] bgp 100
[SwitchA-bgp] peer ex193 route-policy apply_med_50 export
[SwitchA-bgp] peer ex192 route-policy apply_med_100 export
2)
Configure Switch B.
# Configure the VLAN interface IP addresses.
<SwitchB> system-view
[SwitchB] interface vlan 2
[SwitchB-Vlan-interface2] ip address 192.1.1.2 255.255.255.0
[SwitchB-Vlan-interface2] quit
[SwitchB] interface Vlan-interface 4
[SwitchB-Vlan-interface4] ip address 194.1.1.2 255.255.255.0
[SwitchB-Vlan-interface4] quit
# Configure OSPF.
[SwitchB] ospf
[SwitchB-ospf-1] area 0
[SwitchB-ospf-1-area-0.0.0.0] network 194.1.1.0 0.0.0.255
[SwitchB-ospf-1-area-0.0.0.0] network 192.1.1.0 0.0.0.255
[SwitchB-ospf-1-area-0.0.0.0] quit
[SwitchB-ospf-1] quit
# Enable BGP, create a peer group, and add peers to the peer group.
[SwitchB] bgp 200
[SwitchB-bgp] undo synchronization
[SwitchB-bgp] group ex external
