Operation Manual - Information Center
H3C S5500-SI Series Ethernet Switches
Chapter 1 Information Center Configuration.............................................................................. 1-1
1.1 Information Center Overview ............................................................................................. 1-1
1.1.1 Introduction to Information Center........................................................................... 1-1
1.1.2 System Information Format..................................................................................... 1-1
1.2 Configuring Information Center.......................................................................................... 1-4
1.2.1 Configuring to Output System Information to the Console ..................................... 1-5
1.2.2 Configuring to Output System Information to a Monitor Terminal........................... 1-6
1.2.3 Configuring to Output System Information to a Log Host ....................................... 1-7
1.2.4 Configuring to Output System Information to the Trap Buffer................................. 1-8
1.2.5 Configuring to Output System Information to the Log Buffer .................................. 1-9
1.2.6 Configuring to Output System Information to the SNMP NMS ............................. 1-10
1.2.7 Configuring Synchronous Information Output....................................................... 1-11
1.3 Displaying and Maintaining Information Center............................................................... 1-12
1.4 Information Center Configuration Example ..................................................................... 1-12
1.4.1 Outputting Log Information to a Unix Log Host..................................................... 1-12
1.4.2 Outputting Log Information to a Linux Log Host ................................................... 1-14
1.4.3 Outputting Log Information to the Console ........................................................... 1-16
Table of Contents
i
Table of Contents
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for H3C S5500-SI Series
Summary of Contents for H3C S5500-SI Series
-
Page 1: Table Of Contents
Operation Manual – Information Center H3C S5500-SI Series Ethernet Switches Table of Contents Table of Contents Chapter 1 Information Center Configuration................1-1 1.1 Information Center Overview ..................... 1-1 1.1.1 Introduction to Information Center................1-1 1.1.2 System Information Format..................1-1 1.2 Configuring Information Center..................1-4 1.2.1 Configuring to Output System Information to the Console ........ -
Page 2: Chapter 1 Information Center Configuration
Operation Manual – Information Center H3C S5500-SI Series Ethernet Switches Chapter 1 Information Center Configuration Chapter 1 Information Center Configuration 1.1 Information Center Overview 1.1.1 Introduction to Information Center Acting as the system information hub, information center classifies and manages system information. - Page 3 Operation Manual – Information Center H3C S5500-SI Series Ethernet Switches Chapter 1 Information Center Configuration III. Sysname Sysname is the system name of the current host. Users can use the sysname command to modify the sysname. Note that there is a space between the sysname and module fields.
- Page 4 Operation Manual – Information Center H3C S5500-SI Series Ethernet Switches Chapter 1 Information Center Configuration Module name Description Routing Management module RMON Remote monitor module Revest, Shamir and Adleman module SHELL User interface module SNMP Simple Network Management Protocol module...
-
Page 5: Configuring Information Center
Operation Manual – Information Center H3C S5500-SI Series Ethernet Switches Chapter 1 Information Center Configuration Severity Severity Value Description informational Normal prompts debugging Debugging prompts Information filtering by severity works this way: information with severity value greater than the configured threshold will not be output during the filtering. -
Page 6: Configuring To Output System Information To The Console
Operation Manual – Information Center H3C S5500-SI Series Ethernet Switches Chapter 1 Information Center Configuration Output direction Information channel No. Default channel name Note: NMS = Network Management Station Note: Configurations for the six output directions function independently and take effect only after the information center has been enabled. -
Page 7: Configuring To Output System Information To A Monitor Terminal
Operation Manual – Information Center H3C S5500-SI Series Ethernet Switches Chapter 1 Information Center Configuration II. Enabling the display of system information on the console After configuring to output system information to the console, you need to enable the associated display function in order to display the output information on the console. -
Page 8: Configuring To Output System Information To A Log Host
Operation Manual – Information Center H3C S5500-SI Series Ethernet Switches Chapter 1 Information Center Configuration To do… Use the command… Remarks info-center source { modu-name | default } channel channel-number Configure the source of channel-name } [ debug Required the output information... -
Page 9: Configuring To Output System Information To The Trap Buffer
Operation Manual – Information Center H3C S5500-SI Series Ethernet Switches Chapter 1 Information Center Configuration To do… Use the command… Remarks — Enter system view system-view Optional Enable information center info-center enable Enabled by default Optional info-center channel Name the channel with a... -
Page 10: Configuring To Output System Information To The Log Buffer
Operation Manual – Information Center H3C S5500-SI Series Ethernet Switches Chapter 1 Information Center Configuration To do… Use the command… Remarks Optional info-center channel Name the channel with a channel-number name Refer to Table 1-3 for specified channel number channel-name... -
Page 11: Configuring To Output System Information To The Snmp Nms
Operation Manual – Information Center H3C S5500-SI Series Ethernet Switches Chapter 1 Information Center Configuration To do… Use the command… Remarks info-center source { modu-name | default } channel channel-number Configure the source of channel-name } [ debug Required the output information... -
Page 12: Configuring Synchronous Information Output
Operation Manual – Information Center H3C S5500-SI Series Ethernet Switches Chapter 1 Information Center Configuration To do… Use the command… Remarks Optional By default, the time stamp info-center timestamp Configure the format of trap { log | trap | debugging }... -
Page 13: Displaying And Maintaining Information Center
Operation Manual – Information Center H3C S5500-SI Series Ethernet Switches Chapter 1 Information Center Configuration Note: If no information is input from the user following the current command line prompt, the system will not display any command line prompt after system information output. - Page 14 Operation Manual – Information Center H3C S5500-SI Series Ethernet Switches Chapter 1 Information Center Configuration The log information is in English and the source modules are ARP and CMD. II. Network diagram Netw Netw Netw Netw Netw Netw 1.1.0.1/16 1.1.0.1/16 1.2.0.1/16...
-
Page 15: Outputting Log Information To A Linux Log Host
Operation Manual – Information Center H3C S5500-SI Series Ethernet Switches Chapter 1 Information Center Configuration The following configurations were made on SunOS 4.0 which has similar configurations to the Unix operating systems implemented by other vendors. Step 1: issue the following commands as a root user. - Page 16 Operation Manual – Information Center H3C S5500-SI Series Ethernet Switches Chapter 1 Information Center Configuration II. Network diagram Networ Networ Networ Networ Networ Networ 1.1.0.1/16 1.1.0.1/16 1.2.0.1/16 1.2.0.1/16 Switch Switch Switch Switch Switch Switch Switch Switch Switch Figure 1-2 Network diagram for outputting log information to a Linux log host III.
-
Page 17: Outputting Log Information To The Console
Operation Manual – Information Center H3C S5500-SI Series Ethernet Switches Chapter 1 Information Center Configuration Step 2: Edit the file /etc/syslog.conf as a root user and add the following selector/action pair. # H3C configuration messages local7.info /var/log/H3C/information Note: Be aware of the following issues while editing the /etc/syslog.conf file: Comments must be on a separate line and must begin with the # sign. - Page 18 Operation Manual – Information Center H3C S5500-SI Series Ethernet Switches Chapter 1 Information Center Configuration II. Network diagram console console console Console console console console Console Switch Switch Switch Switch Switch Switch Switch Switch Figure 1-3 Network diagram for sending log information to the console III.
