Appendix B: Integrating Cisco Unified Communications Manager and Cisco Unified SRST to Use Cisco Unified SRST
Regions specify the codecs that are used for audio and video calls within a region and between existing
regions. For information about regions, see the "Region Configuration" section in the Cisco Unified
Communications Manager Administration Guide. From the
Manager
Cisco Unified Communications Manager version to locate the administration guide for your version.
Figure 4
Configure MOH Server
Add Server
Add MRG
Configuring the MOH Audio Source to Enable Multicasting
The MOH audio source is a file from which Cisco Unified CM transmits RTP packets. You can create
an audio file or use the default audio file. For Cisco Unified SRST multicast MOH, only one audio source
can be used, even if, for example, one out of 500 sites uses Cisco Unified SRST multicast MOH. In
addition, all Cisco Unified Communications Manager systems must use the same audio source for user
and network MOH because Cisco Unified SRST multicast MOH can stream audio only to a single
multicast IP address and port. For Cisco Unified SRST multicast MOH, the Cisco Unified
Communications Manager audio source file must be configured for G.711 bandwidth.
OL-13143-04
documentation directory, click Maintain and Operate Guides and select the required
Unified Communications Manager Screens for Configuring Multicast MOH
Music On Hold (MOH) Audio Source Configuration Screen
Music On Hold (MOH) Server Configuration Screen
Media Resource Group Configuration Screen
Media Resource Group Configuration Screen
Phone Configuration Screen
Gateway Configuration Screen
How to Use Cisco Unified SRST Gateways as a Multicast MOH Resource
