Infors HT MULTITRON STANDARD Operating Manual page 94

Multitron Standard - Operating manual
Technical Data
Maximum Permissible Setpoints for
the Rotation Speed
Page 94 of 104
The following information is based on an ideal tray
load of 14 kg made up of standard Erlenmeyer flasks
with no baffles and a fill level of 30%. For informa-
tion on the optimum load weight depending on the
rotation speed, see ⮫ Chapter 11.3.3 'Ideal Loading
Weights' on page 96.
The following guidelines for maximum rotation speeds are specified
to prevent damage. Hence, they must be observed though further
restrictions (e.g. tray with Sticky Stuff adhesive matting) must be taken
into account.
The minimum rotation speed for all unit variants is 20 min
imum rotation speed of a device unit depends on the throw and the
position of the unit in the stack:
Single unit
Two units stacked (low
base)
Top unit
Bottom unit
Two units stacked (high
base)
Top unit
Bottom unit
Three units stacked
Top unit
Middle unit
Bottom unit
All these values are intended solely as guidelines (not guaranteed).
Depending on the load, higher rotation speeds are possible; in this
case, the rotation speed should be increased slowly. In such cases,
the user is responsible for determining the maximum possible rotation
speed based on the vibrations and the vessel holders (the clamps
may need to be secured) and communicating them. If vibrations occur,
reduce the shaking speed until the device runs smoothly. Alternatively,
increase or decrease the load until the device runs smoothly.
25 mm throw 50 mm throw
400 min 350 min
-1
25 mm throw 50 mm throw
400 min 300 min
-1
400 min 350 min
-1
25 mm throw 50 mm throw
250 min 250 min
-1
400 min 350 min
-1
25 mm throw 50 mm throw
350 min 250 min
-1
400 min 300 min
-1
400 min 350 min
-1
. The max-
-1
-1
-1
-1
-1
-1
-1
-1
-1
29.11.2024
