Multitron Standard - Operating manual
Overview of the Device
Operating ele- Designation
ment
Minus button
1.3.2 Display Elements
Symbol Designation
Rotation speed
RPM
Temperature
°C
Timer
External (EX)
EX
Cycle active
Next phase (FT)
FT
Timer active
Power supply
On/Off
Page 12 of 104
Function
The Minus button decreases the values of the parameter setpoints
or the time of the timer function. When the button is held down,
the display runs down the specified value range in increasingly large
intervals.
Meaning
Indicates that the rotation speed (setpoint or actual value) is being
displayed in the corresponding view box.
Indicates that the temperature (setpoint or actual value) is being
displayed in the corresponding view box.
Indicates that the timer function (length of time unit) can be
adjusted.
Indicates that the device is being accessed by an external device.
This symbol also lights up, for example, if external software (e.g.
eve ) is being used to access the device.
®
Indicates that the cycle function (constant switching between
phases 1 and 2) is active.
Indicates that the parameters for the second phase (FT) can be
adjusted.
Indicates that the timer function is active.
Indicates that the device is switched on and the initialisation proce-
dure is complete.
