Infors HT MULTITRON STANDARD Operating Manual page 9

Interior
2
1
Kopiervorlagen diverse
7
1 Table
2 Working light
Kopiervorlage Bilderrahmen
3 Tray lock
4 Cylindrical ball caster
Short Description
29.11.2024
3
Kopiervorlagen diverse
Kopiervorlagen diverse
Kopiervorlage Bilderrahmen
Kopiervorlage Bilderrahmen
The Multitron Standard incubator shaker is used to cultivate microor-
ganisms or cell cultures in a laboratory environment. The basic version
of the device is fitted with a shaker drive and a heater. Depending on
which version of the device, it will come with either a 25 mm or a
50 mm throw. The device can also be fitted with an optional cooling
system mounted on the top of the device.
The device can be operated either locally, using the operating panel
on the front of the device, or remotely, using a computer connected
to the device via an Ethernet interface.
Multitron Standard - Operating manual
Overview of the Device
6
5 Slide rail
6 Screw-mounted pin
7 Stop bar
4
5
Page 9 of 104
