Infors HT MULTITRON STANDARD Operating Manual page 30

Multitron Standard - Operating manual
Setup and Function
3.5 Substructure
Page 30 of 104
Different versions of the incubator shaker are available with different
substructures:
Rubber Feet
Low Base
High Base
Single units placed on a bench have a
substructure comprising an earthing
plate with 7 rubber feet. The rubber
feet are bolted onto the earthing
plate at a fixed height, and cannot be
adjusted. As such, table top models
must always be placed on an even
surface.
Single and stacked units can be fitted
with a 13 cm base. The base has an
adjustable foot that can be used to
level the device.
Single units and two units stacked
can be fitted with a 31 cm base. The
base has an adjustable foot that can
be used to level the device.
29.11.2024
