Infors HT MULTITRON STANDARD Operating Manual page 37

Technical Data
4.1.4 Tray with Clamping Assembly
Overview
29.11.2024
NOTICE
The spacers are made of plastic and therefore cannot be autoclaved.
Data
Material
Fastening screws
Cleaning
Disinfection
Sterilisation in an autoclave
External dimensions of the
microtitre plates
Height of the deep-well plates
To affix microtitre and deep-well plates, there is a quick clamping
assembly. Two versions of this clamping assembly are available:
Tray with flat clamping assembly (horizontal incubation): The flat
clamping assembly is a profile made of sheet metal that is equipped
with an angled strip (2). On the other side, there is an edge featuring
a foam rubber strip (3). There are two spacers on the edge (1) for
positioning microtitre plates or deep-well plates.
Multitron Standard - Operating manual
Accessories
Quickload spacers are long plastic strips
(4 mm high) that span across several
plates, thus allowing you to save time
while loading.
Mild neutral cleaning agent
Commercially available
Value
Aluminium
M5 x 12
disinfectant
YES
85.1 x 127 mm
42 mm
Page 37 of 104
