1.3.3 View Boxes
Kopiervorlage Bilderrahmen
Time Information Displays
Fault Displays
29.11.2024
1
RPM
The two view boxes show the current actual values or setpoints of the
parameters as well as alarm and error messages. In normal operation,
the "Rotation speed" parameter (
(1) and the "Temperature" parameter (
box (2).
The parameter is activated: The actual value is displayed.
■
The parameter is deactivated. The display alternates between the
■
setpoint and the message
The F button (or FT button when using the timer) can be used to
navigate between parameters. The parameter that can be set is always
displayed in the right view box. If no entry is made for 60 seconds the
display returns to normal operation.
Time information is displayed as follows in the view boxes:
From 0 to 99 minutes:
■
The time is displayed in
From 1 hour, 40 minutes to 9 hours, 50 minutes:
■
The time is displayed in the format
From 10 to 95 hours:
■
The time is displayed in
From 4 days, 00 hours to 9 days, 23 hours:
■
The time is displayed in the format
For information on the alarms and error messages displayed in
the view boxes, see ⮫ Chapter 7.2 'Messages in the View Boxes'
on page 72.
