Infors HT MULTITRON STANDARD Operating Manual page 46

Multitron Standard - Operating manual
Accessories
Setup
1 2
6
Installation
Loading
Inserting/Replacing a Filter
2
1
Page 46 of 104
1 Filter
2 Filter washer
3 Top plate
3
4 Microtitre insert
5 Quickload spacers
6 Container
5 4
The box for microtitre plates is affixed to the tray with four Philips
head screws. When delivered, the fastening screws are covered with
plastic cap nuts. These must be removed prior to installation.
Alternatively, the box for microtitre plates can be placed on the Sticky
Stuff adhesive matting. In this case, all fastening screws must be
removed to avoid damaging the adhesive matting.
During installation, ensure that the tray is always loaded evenly.
To improve transfer of oxygen to the cultures and facilitate the
removal of the plates, spacers (Quickload Spacers) (1) can be placed
between the individual layers. Prior to loading, the Quickload Spacers
must be removed. Following that, microtitre or deep-well plates can
be inserted.
For cultivations with a low oxygen requirements, Quickload Spacers
do not have to be used.
1
To insert or replace a sterile filter (3) the filter washer (2) must be
removed first. To do so, press the locking button (1) on the filter
washer and lift up the filter washer. Following that, the filter can be
inserted and the filter washer can be put back in its place.
3
29.11.2024
