Multitron Standard - Operating manual
Operation
Setting the Setpoints for Phase 1 (FT Button)
Kopiervorlagen diverse
Setting the Timer for Phase 1 (F Button)
Kopiervorlage Bilderrahmen
Page 64 of 104
Kopiervorlagen diverse Kopiervorlagen diverse Kopiervorlagen diverse
Kopiervorlage Bilderrahmen Kopiervorlage Bilderrahmen Kopiervorlage Bilderrahmen
RPM
1.
2.
Kopiervorlagen diverse Kopiervorlagen diverse Kopiervorlagen diverse
3.
4.
1
Kopiervorlage Bilderrahmen Kopiervorlage Bilderrahmen Kopiervorlage Bilderrahmen
RPM
5.
6.
7.
°C
Press the F button (1) to select the parameter (RPM or °C) in
question.
Press the Plus or Minus button (2) to set the setpoint you want
to use for the selected parameter.
Press the On/Off button (3) to activate the parameter.
Repeat steps 1 – 3 as necessary for the other parameters.
Press the F button (3) to select the timer function
Timer parameter symbol (2) lights up.
�� The
Use the Plus or Minus button (4) to set the required duration.
Press the On/Off button (5) to activate the timer.
Timer active function symbol (1) will flash.
�� The
1 2
F
FT
2 3 4
F
FT
3
5
