Multitron Standard - Operating manual
Operation
Removing the Tray
Inserting the Tray
Page 56 of 104
To remove the tray, proceed as follows:
1. Open the device door all the way.
�� The safety mechanism unlocks the lock hooks (2) automati-
cally when the door is opened, and lifts the tray out of the
rear cones (4).
2. Lift the tray by the handle and pull it onto the open door.
If you cannot pull the tray out, check whether
the door is open all the way. Push the door
down as far as it will go.
The insertion of the tray works independently of the position of the
table. Proceed as follows:
1. Open the device door all the way.
2. Place the tray on the slide rails of the doors (6).
3. Push the tray between the guide rails (3) up to the limit stop (1)
in the incubation chamber.
4. Check whether the tray is placed properly behind the front stop
bar (8).
5. Close the device door.
�� When the door closes, the ejection levers lower and the tray
is lowered into the two cones (4). At the same time, the lock
hooks (2) move forwards to secure the tray to the table.
6. Check whether the lock hooks hold the tray in place securely
when closing the door.
NOTICE
If the tray is not held in place securely on the table, the tray's
movement may damage the interior of the device.
− Do not start up the device unless the tray has been inserted
correctly and affixed securely.
