3.1.2 Temperature Control (Heating)
Function
Kopiervorlage Bilderrahmen
Operation
°C
29.11.2024
Kopiervorlagen diverse
Kopiervorlage Bilderrahmen
1 Cross-flow fan
2 Pt100 sensor
The temperature is controlled via two cross-flow fans (1), which are
each equipped with a downstream heating element. The cross-flow
fans ensure constant air circulation, and keep the temperature distri-
bution in the incubation chamber as constant and gradient-free as
possible.
The maximum possible temperature in the incubation chamber is 65°C,
the minimum temperature is 6°C above the ambient temperature. In
order to reach temperatures below the ambient temperature, the
device can be fitted with an optional cooling system (⮫ Chapter 3.1.3
'Optional Cooling Function' on page 26),
A Pt100 temperature sensor behind the rear wall (2, not visible) meas-
ures and controls the temperature.
The heater is operated using the "Temperature" (°C) parameter. For an
exact description of how to set the parameters, see ⮫ Chapter 6.3
'Setting, Activating and Deactivating Parameters' on page 60.
Multitron Standard - Operating manual
Setup and Function
1
2
Page 25 of 104
