A-10
Connector Pin Assignments
Power LED Connector
The following figure shows the power LED connector on the system board. Table
Appendix A-9 provides the pin assignments.
Table Appendix A-9 Power LED Pin Assignments
Pin
1
2
3
Reset Button Connector
The following figure shows the reset button connector on the system board. Table
Appendix A-10 provides the pin assignments.
Pin
1
2
1
3
SPKR
RST PWRLED
Figure Appendix A-8 Power LED Connector
Signal Name
LED_PWR (green)
Key
Ground (blue)
1 2
SPKR
RST PWRLED
Figure Appendix A-9 Reset Button Connector
Table Appendix A-10 Reset Pin Assignments
Signal Name
RESET
Ground
HDLED INFRARED
SLP
HDLED INFRARED
SLP
RP
RP
