A-8 Connector Pin Assignments

HARD DRIVE LED CONNECTOR

The following figure shows the hard disk LED connector on the system board. Table A-8
provides the pin assignments.
Pin
1
2
3
4

POWER LED CONNECTOR

The following figure shows the power LED connector on the system board. Table A-9
provides the pin assignments.
1
SPKR RST PWRLED HDLED INFRARED
Figure A-7 Hard Disk LED Connector
Table A-8 Hard Disk LED Pin Assignments
Signal Name
+5V (white)
HD ACTIVE
Key
+5V
3
1
SPKR RST PWRLED HDLED INFRARED
Figure A-8 Power LED Connector
4
SLP RP
SLP RP
