Serial/Modem Sub-Tab
The Serial/Modem tab contains two tabs: Serial Port Parameters and Modem
Control.
Serial Port Parameters
Figure 49. Printer Properties: Connections – Serial/Modem Sub-Tab
Connect Using: The serial port to use for connection. The default is COM1.
The range is COM1 to COM20.
Speed: The baud rate at which data transfers. This setting must match the
speed of the printer serial debug port. See Table 4 to determine the serial
debug port baud rate menu location for your printer model
Table 4. Serial Debug Port Baud Rate Menu Location
Printer Model
SL4M/T4M INTERFACES Printer Mgmt Baud Rate
SL5000r/T5000r PRINTER MGMT or Factory Baud Rate
SL5000e/T5000e Factory Baud Rate
P7000 PRINTER MGMT BAUD RATE
P5000 Factory PRINTER MGMT BAUD RATE
Word Size: The number of data bits per character. Must be set to 8 bits.
Parity: Adds an error checking bit if set to Odd or Even. Since the word size
must be set to 8 for correct operation, parity should normally be set to None.
Stop Bits: Inter-character gap. Can be set to 1 or 2. The normal setting is 1.
