Report Generation - Printronix T5000 Software Manual

Report Generation

If you change the Data Capture file name to a name that already exists, the
telemetry data stored in the existing file will not be erased. All new telemetry
data will be appended to the existing file.
NOTE: You cannot change the Data Capture file name while telemetry data
is being captured.
The AutoID Data Manager never erases the Data Capture file. To delete a
Data Capture file, locate and delete the file from the default location, program
installation directory, or where it was created (it has a .dm extension).
Report Generation
To export telemetry data to an ASCII file in either CSV or XML format, select a
printer or group of printers and then select one of the report generation
options (see "Reports" on page 261).
After the report is created, a dialog box appears giving the status, location,
and name of the report. See Figure 230. Write down this information for future
reference. Click OK to close the dialog box.
Report Report
Name Location
Figure 230. Report Creation Completed Dialog Box
263
