Printronix T5000 Software Manual page 256

Chapter 6
Technical Information
(*) Pin 17 is connected to a number of through holes on the GPIO printed
circuit board. It can be used to supply power (via a user-installed resistor) to
the collectors of the output transistors. See the diagram of the outputs on
page 258.
256
Table 14 : Connector Wiring
1: IP1A 18: OP1C
2: IP2A 19: OP2C
3: IP3A 20: OP3C
4: IP4A 21: OP4C
5: IP5A 22: OP5C
6: IP6A 23: OP6C
7: IP7A 24: OP7C
8: IP8A 25: OP8C
9: IP1C 26: OP1E
10: IP2C 27: OP2E
11: IP3C 28: OP3E
12: IP4C 29: OP4E
13: IP5C 30: OP5E
14: IP6C 31: OP6E
15: IP7C 32: OP7E
16: IP8C 33: OP8E
17: (*)
34:R1CM
35:R2CM
36:R3CM
37:R4CM
38:R1NC
39:R2NC
40:R3NC
41:R4NC
42:R1NO
43:R2NO
44:R3NO
45:R4NO
46: n.c.
47:+5V
48:5Vret
49:+24V
50:24Vret
