Figure 153. Hex Entry Mode
39. Type 1B. To enter the hex equivalent of <ESC>. See Figure 153.
Figure 154. Mnemonics Entry Mode
40. Right-click the Input window and select View Mnemonics. To enter the
Mnemonics entry mode. Notice the 1B changed to <ESC>. See
Figure 154.
41. Type D0123,0450,0600.
42. Right-click the Input window and select View Hex.
43. Click just to the right of 0010 on the second line.
Figure 155. Hex Equivalents of LF and NUL
44. Type 0A00. To enter the hex equivalent of LF and NUL. See Figure 155.
45. Right-click the Input window and select View Mnemonics.
46. Click Run to test the CST against your input.
Figure 156. Successful CST Test Results
The length and width information have successfully been placed in the correct
position in the PGL command. See Figure 156.
NOTE: If a value outside the specified range (in this case, outside the range
0..9) is entered, no conversion takes place and the input string is
passed on to the printer unmodified.
Pattern Recognition Example
