Printronix T5000 Software Manual page 13

6. If you have the internal PCI NIC, press
If you have the external NIC, press
7. Press ENTER to select it.
8. Press and at the same time to lock the ENTER key.
9. Press ON LINE CLEAR to put the printer back online.
P5000 Series Line Matrix Printers
1. On the operator panel, press the ON LINE CLEAR key to take the printer
offline.
2. Press UP and DOWN at the same time to unlock the ENTER key.
3. Press PREV, NEXT, UP, and DOWN at the same time to enter the
Factory menu.
4. Press NEXT until PRINTER MGMT displays.
5. Press DOWN until DIAGNOSTIC PORT displays.
6. Press DOWN again to see the current selection.
7. Press NEXT until Debug Ethernet or Debug Adapter displays.
8. Press ENTER to select it.
9. Press UP and DOWN at the same time to lock the ENTER key.
10. Press ON LINE CLEAR to put the printer back online.
SL5000r/T5000r Series Thermal Printers
1. On the operator panel, press the PAUSE key to take the printer offline.
. .
2. Press to place the printer in Menu mode. QUICK SETUP displays on
.
the operator panel.
↵
3. Press ↓ and
at the same time to unlock the
4. Press + until PRINTER MGMT displays.
5. Press ↓ until PNE Port displays.
NOTE: If PNE Port does not display, see "Factory Menu" below.
6. If you have the internal PCI NIC, press + until Ethernet displays. If you
have the external NIC, press + until Adapter displays.
↵
7. Press to select it.
↵
8. Press ↓ and
at the same time to lock the
9. Press PAUSE twice to put the printer back online.
Factory Menu
1. On the operator panel, press the PAUSE key to take the printer offline.
↵
2. Press ↓ and
at the same time to unlock the
3. Press +, –, ↓, and ↑ at the same time to enter the Factory menu.
4. Press ↓ until PNE Port (or Diagnostic Port) displays.
Operator Panel Method
until Ethernet displays.
until Adapter displays.
↵
key.
↵
key.
↵
key.
13
