6. Failure Code
Bar Code
This is the hex value assigned for each type of failure, shown below.
See "7. Failure Message" on page 270.
Failure Code Failure Code
(Hex)
0000 0000 0000 0000 0000
0001 xxxx xxxx xxxx xxx1
0002 xxxx xxxx xxxx xx1x
0004 xxxx xxxx xxxx x1xx
0008 xxxx xxxx xxxx 1xxx
0010 xxxx xxxx xxx1 xxxx
0020 xxxx xxxx xx1x xxxx
0040 xxxx xxxx x1xx xxxx
0080 xxxx xxxx 1xxx xxxx
0100 xxxx xxx1 xxxx xxxx
0200 xxxx xx1x xxxx xxxx
0400 xxxx x1xx xxxx xxxx
0800 xxxx 1xxx xxxx xxxx
1000 xxx1 xxxx xxxx xxxx
2000 xx1x xxxx xxxx xxxx
4000 x1xx xxxx xxxx xxxx
8000 1xxx xxxx xxxx xxxx
NOTE: The hex values listed above reflect single failures.
Multiple failures will create additional hex values based on the binary
weighting shown.
For example, the hex value 0042 (or binary 0000 0000 0100 0010)
represents both the Encodation and Decodeability failures.
RFID
This is the hex value assigned for an RFID failure.
0 = no RFID failure
1 = RFID failure
Failure Message
(Binary)
No error
PDF 417 Gap
Decodeability
Defect
Percent Decode
Quiet Zone
(Symbol) Contrast
Encodation
Checksum
Calibration
Overall Grade Failure
Internal Data Format Error
Modulation
Minimum Reflectance
Minimum Edge Contrast
Future use
Future use
Viewing Telemetry Data
