Chapter 6
Overview
Action Name
3 Performs an action on a user-
Timers/RTC
defined timer. If no timers are
defined, the user is asked to define
timers first.
1
Thermal only.
2
Impact only.
3
If no instances of this object type are defined, the user is prompted to define the
types now.
If the user selects Cancel, the action will revert to the previous selected action.
Action Descriptions
•
Figure 183. Setting Ouput Opto-coupler Action Parameters
216
Table 10. Event Actions and Parameters
Description
Output Opto-Couplers
The opto-coupler number to activate can be specified as well as the level
(or state) required for this output. Select the state by clicking the opto-
coupler symbol. If the Pulse parameter is selected, the pulse duration can
be set in increments of 50 msec between 50 and 2,147,483,647 msec.
This allows pulses up to 24.8 days in duration. If Repeated Pulse is
selected, the pulse will repeat with a 50% duty cycle until deactivated.
Parameters
Timer, Action
Security Key
Required
