1.1 Creel Assembly

The following figure shows the details for a correct assembly of the creel modules.
This example refers to a creel with4 stacked modules.
5
6
No. Description
1 TMS SENSOR
2 ELECTRICAL BOX
3 MTX/TOUCH/DIAPER TERMINAL
4 WHEELED BASE FOR SINGLE COLUMN
5 SUPPORT FOR JOINTED BRACKET WITH WHEELS FOR YARN
OUTPUT FROM SINGLE COLUMN
6
FEETED BASE FOR SINGLE COLUMN
7
SINGLE MODULE FOR MATRIX CUBE (MCC)
Figure 7 - Assembly of the creel module
MATRIX CUBE (MCC)
Installation and Connections
2
3
4
Code
TMS/D1000/ΔΔ/AW/IP
MCC/MCFB/□□□/□
MCC/DMT/001
MCC/BCS/001
MCC/MCW/001
MCC/BMS/002
MCC/M3L/001
1
