Compliance with European Directives and Standards

The creels of the MATRIX CUBE (MCC) system comply with the safety requirements provided by Machinery Directive
2006/42/CE and with the Electromagnetic Compatibility requirement provided by EMC Directive 2014/30/UE. The
electronic parts of the system comply with the requirements provided by Directive 2011/65/EC - RoHS III.
During the design and manufacturing stages of BTSR equipment, the relevant paragraphs of the following Harmonized
Standards have also been used as reference and guide line.

Applicable Directives

Machinery Directive
Electromagnetic Compatibility Directive
RoHS III Directive

Main Harmonized Standards Applied

Safety of machinery - General principles for design - Risk assessment and risk reduction
Electromagnetic compatibility (EMC). Part 6-2: Generic standards - Immunity for
industrial environments.
Electromagnetic compatibility (EMC). Part 6-4: Generic standards - Emission standard
for industrial environments.
Electrical equipment for measurement, control and laboratory use - EMC requirements
-- Part 1: General requirements
Safety of machinery. Electrical equipment of machines. Part 1: General requirements.
Safety of machinery. Safety-related parts of control systems. Part 1: General principles
for design.
Safety of machinery. Safety-related parts of control systems. Part 2: Validation
Technical documentation for the assessment of electrical and electronic products with
respect to the restriction of hazardous substances

Noise Levels

The MATRIX CUBE (MCC) creels have been designed and manufactured to reduce the noise to minimum levels during
operation. Weighted A acoustic pressure level generated by the machine and measured (following the criteria defined
by the standards in force) at the operator working zones, during normal operation, is less than 70 db (A)

Safety and Reliability of Control Systems

Within the DIAPERFEEDER device, the only safety control system (motor locking prior to carry out the threading
operation) has been implemented according to the principles of the Harmonized Norm EN ISO 13849-1:2015. The
following table shows the values of Category and of Performance Level (PL) implemented (with respect to the Required
Performance Level (PLr) resulting from the risk assessment).
The PL calculation has been carried out by means of the "SISTEMA" (IFA) software.
Safety function
Wheel motor safety stop during the threading
operation.
The PL value calculation and the relevant "SISTEMA" report are included within the Technical File of the MATRIX CUBE
(MCC) system.
2006/42/CE
2014/30/UE
2011/65/CE
Category
1
MATRIX CUBE (MCC)
Introduction
from 29/12/2009
from 20/04/2016
from 22/07/2017
EN ISO 12100:2010
EN 61000-6-2:2019
EN 61000-6-4:2019
EN 61326-1:2022
EN 60204-1:2018
EN ISO13849-1:2023
EN ISO13849-2:2012
CEI EN 63000:2021
PL PLr
b b
