1.12 Configuration of DIAPER FEEDER Devices

Even though the operating parameters of DIAPER FEEDER devices can be programmed locally using the built-in
Keyboard and Display, for MATRIX CUBE application the programming is normally carried out using the MATRIX TOUCH
DIAPER terminal, through the SM-DIN Board (SM-DIN is Master of DIAPER FEEDER device, and receives input from
MATRIX TOUCH DIAPER or PLC).

1.13 Configuration of TMS Sensors

The configuration of TMS operating parameters is carried out using the MATRIX TOUCH DIAPER terminal or through the
SM-DIN Board and basically consists in Identification and Calibration (offset).
Note 1: For more details about the programming of DIAPERFEEDER devices and TMS sensors, please refer to the
relevant manual.
Note2: Pay attention to the sensor positioning, direction of elastic yarn and elastic path on the sensor according to
specific configuration.
Figure 24 – DIAPER FEEDER keyboard and display
TB Configuration
TT Configuration
Figure 25 – Configuration of TMS Sensors
MATRIX CUBE (MCC)
Installation and Connections
Display
Keyboard
BB Configuration
BT Configuration
