btsr MATRIX CUBE User Manual page 11

The creels structure can be freely configured thanks to the availability of basic configurations. Below are listed the most
common configuration and represented related layout.
Basic configurations
Code
□□□
∆∆
MCC/M3L/4/ / /P/*
□□□
∆∆
MCC/M3L/6/2/ /
□□□
∆∆
MCC/M3L/8/2/ /
□□□
∆∆
MCC/M3L/5/ / /P/*
∆∆
= TMS sensor wheel position
□□□
= communication type
P
= additional pulley set
*
= power supply type
For more information, please refer to paragraph 1.1 Creel assembly.
For the correct number and code of necessary accessories, in case of complex configurations (high number of creel
modules) please contact your BTSR dealer.
Creel module composition
/P/*
/P/*
MATRIX CUBE (MCC)
Introduction
Notes
Each configuration includes a
specific number of elements and
accessories.
For more information, please
contact your BTSR dealer.
- v -
