Maintenance
3.1.3 – Efficiency check and cleaning of rotating elements in contact with the yarn
Thoroughly check efficiency and clean yarn and dirtiness residues from all rotating elements in contact with the yarn, as
shown on the following examples figures.
Check and Cleaning the wheels along the yarn path (surface and efficiency of bearings)
Wheel assembly
Figure 42 – Check and Cleaning the wheels
Check and Cleaning the wheels along the yarn path (surface and efficiency of bearings)
Figure 43 – Check and Cleaning the wheels
